MONROE 66921 Magnum Suspension Shock Absorber

$64.49

Limited availability at this price!

In Stock

Get it by Monday, Feb 23
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 66921 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES   -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 66921 Specifications

Product Attributes

Lower Mount Code S5
Upper Mount Code S5
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 13.5 IN
Dust Shield Material Metal
Extended Length 23.625 in
Gas Charged Yes
Lower Mount Type Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch
Parts Pack(s) (2) P01303
Travel Length 10.125 in
Upper Mount Type Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch
Compressed Length 342.9 MM
Extended Length 600.1 MM
Travel Length 257.2 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Base of Stem
Lower Mount Type Stem
Lower Mount Code S5
Upper Mount Code S5
Mounting Hardware Included Yes
Grade Type Premium
Active or Passive Suspension Passive
Adjustable Compression No
Adjustable Rebound No
Adjustable Ride Height No

Additional Information

MSDS Sheet Number 01164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708800050
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598074249
VMRS Code 016008003
UNSPSC 25172011

MONROE 66921 Cross References

BrandPart Number
66921MM
BULLDOG HD SHOCKSHD1214-0661
CHEVROLET3919922
EUCLIDE83318
GABRIEL83318, 727645
GM3919922
General Motors3919922
Gold Shock Absorber8160099
HALDEXSA66921
INTERNATIONAL472414C91, AMS600131, AMS660131, 472367C91
KYBKG6201
MACK600131MT, 660131MT, 600131
MERITORM83318
MONROE VINTAGE6921, 601131, 661131, 660131
MOTORCRAFTCAX921
Monroe Shocks & Struts601131, 660131, 661131, 6921
NAPA Shocks66921
NEWAY57366921, 57306921
NUTURN/LELANDL59098
Navistar472367C91, 472414C91, AMS600131, AMS660131
VOLVO / WHITE / GMC3919922
Volvo GM Heavy Truck3919922
WORLD AMERICANWA01-83318

MONROE 66921 Fits Vehicles

  • International 2155 (1984-1989)
  • International 1754 (1981-1989)
  • International 1955 (1981-1989)
  • International 1854 (1981-1989)
  • International 1724 (1980-1984)
  • International 1654 (1980-1989)
  • International F1924 (1979-1981)
  • International 1925 S (1979-1982)
  • International 1824 (1979-1984)
  • International 1954 (1979-1989)
  • International 1924 S (1979-1982)
  • International F1954 (1979-1989)
  • International S1723 (1980-1985)
  • International M1600 Metro II (1987-1990)
