MONROE 65483 Magnum Amortisseur

★★★★★ (0)
Monroe 65483 Suspension Shock Absorber Magnum Amortisseur
MONROE
Tap to view 3 more

$99.49

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

MONROE 65483 Part Description

Manufacturer

MONROE

Product Description

Magnum Rear Suspension Shock Absorber

Features & Benefits

  • INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65483 Specifications

Product Attributes

Compressed Length18.125 IN
Compressed Length460.4 MM
Extended Length29.5 in
Extended Length749.3 MM
Travel Length11.375 in
Travel Length288.9 MM
Lower Mount TypeLoop Bushing and Sleeve Mount - 20MM Sleeve ID X 1.3/4" Sleeve OAL
Lower Mount TypeLoop (Eyelet) Bushing and Sleeve
Lower Mount CodeLS75
Upper Mount TypeLoop Bushing and Sleeve Mount - 20MM Sleeve ID X 44.45MM Sleeve OAL
Upper Mount CodeLS75
Shock Absorber Rod End Measuring PointCenter of Loop
Shock Absorber Body End Measuring PointCenter of Loop
Gas ChargedYes
Mounting Hardware IncludedNo
Parts Pack(s)None
Body ColorBlack
Cylinder ColorBlack
ColorBlack
Cylinder FinishPainted
Dust Shield IncludedYes
Dust Shield MaterialMetal
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutYes
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01164
Country of Origin (Primary)US
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598173836
VMRS Code016008003
UNSPSC25172011

MONROE 65483 Cross References

BrandPart Number
65483MM, MAE65483
AutomannA83148
BULLDOG HD SHOCKSHD1215-0083
Bulldog HDHD12150083
Dayton Parts44185978
FCSF347235, F347277, F344355
FOX COMMERCIAL TRUCK SHOCKS98031030
FordFC4Z18125D, FC4Z18125E
GABRIEL85978, 83148
Gold Shock Absorber9180201
HALDEXSA65483
HENDRICKSON606755, 98583006, 60670011, 60675005, 59048001, 6067011, 586231, 606751, 60670020, 606652, 60670017, 6067013, 60670013
HINO6067013
Hendrickson60675001, 60675001L
KYBKG6007, 6460006
MERITORM83148
MOTORCRAFTASH25838, ASH24663
Mack60675001, 8083872, 14QK423M
NAPA Shocks65483
OEMFC4Z18125D, 60675001, 60670013, FC4Z18125E, 8083872
POWER10 PARTSH-60670-013, H-60675-001, H-60675-009, SSA-85978
SACHS NORTH AMERICA316822, 317937
Sachs316822, 317937
VOLVO / WHITE / GMCSA3148, 8083872, 400060670011, RCSA3148
Volvo60675001, 8083872
Volvo GM Heavy Truck8083872, RCSA3148, SA3148
Volvo Truck400060670011

MONROE 65483 Fits Vehicles

  • Mack Anthem (2018-2024)
  • Mack CHU (2008-2019)
  • Mack CXU (2008-2019)
  • Mack GU4 (2012-2018)
  • Mack GU5 (2012-2018)
  • Mack GU7 (2008-2018)
  • Mack GU8 (2008-2018)
  • Mack Granite (2015-2022)
  • Mack Pinnacle (2019-2022)
  • Mack TD700 (2010-2017)
  • Volvo VAH (2011-2018)
  • Ford F-650 (2016-2019, 2021-2024)
  • Ford F-750 (2016-2019, 2021-2024)
