MONROE 65481 Magnum Amortiguador

★★★★★ (0)
Monroe 65481 Suspension Shock Absorber Magnum Amortiguador
MONROE
Tap to view 3 more

$95.99

Limited availability at this price!

In Stock

Get as soon as Wednesday, Nov 25
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

MONROE 65481 Part Description

Manufacturer

MONROE

Product Description

Magnum Rear Suspension Shock Absorber

Features & Benefits

  • INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65481 Specifications

Product Attributes

Compressed Length16.51 IN
Compressed Length419.4 MM
Extended Length26.71 in
Extended Length678.4 MM
Travel Length10.2 in
Travel Length259.1 MM
Lower Mount TypeLoop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Lower Mount TypeLoop (Eyelet) Bushing and Sleeve
Lower Mount CodeLS54
Upper Mount TypeLoop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Upper Mount CodeLS54
Shock Absorber Rod End Measuring PointCenter of Loop
Shock Absorber Body End Measuring PointCenter of Loop
Gas ChargedYes
Mounting Hardware IncludedNo
Parts Pack(s)None
Body ColorBlack
Cylinder ColorBlack
ColorBlack
Cylinder FinishPainted
Dust Shield IncludedYes
Dust Shield MaterialMetal
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutYes
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01164
Country of Origin (Primary)US
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598173812
VMRS Code016008003
UNSPSC25172011

MONROE 65481 Cross References

BrandPart Number
65481MM, MAE65481
AutomannA85036
BULLDOG HD SHOCKSHD1215-0059
Bulldog HDHD12150059
Dayton Parts441850365481
EUCLIDM89405
FCSF347248, F347302
FORD1C4418080AA, 1C4Z18125AA
GABRIEL85036, 83123, 89405
HALDEXSA65481
HENDRICKSON606704, 60670001, 606708, 4790227, 606654, 598513, 479029, 60670008, 60670008L, 606701
International537524C91
KENWORTH4790219
KYB341624
Kenworth60670008, 60670008L
Koni881559SP1
MACK14QK410M3, 479029, 25625254, 25625235
MERITORM89405, M85036, M83123
NAPA Shocks65481
OEM60670008, 579053, 1C4Z18125AA, 537524C91, 60670008L
PRT HD170246
Peterbilt60670008
REYCO GRANNING2096701
VOLVO / WHITE / GMCSA3123
Volvo GM Heavy TruckSA3123
WESTERN STAR579053

MONROE 65481 Fits Vehicles

  • Kenworth K270 (2013-2023)
  • Kenworth K370 (2013-2022)
  • Kenworth T270 (2008-2023)
  • Kenworth T280 (2021-2024)
  • Kenworth T300 (2007-2008)
  • Kenworth T370 (2008-2023)
  • Mack CH (1989-2005)
  • Mack CL (1991-2007)
  • Peterbilt 220 (2007, 2010, 2013-2022)
  • Ford F-650 (2000-2003)
  • Ford F-750 (2000-2003)
  • IC Corporation RE School Bus (2003-2018)
