(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | LS54 |
| Upper Mount Code | LS54 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 16.95 IN |
| Dust Shield Material | Metal |
| Extended Length | 27.6 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 10.65 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Compressed Length | 430.5 MM |
| Extended Length | 701 MM |
| Travel Length | 270.5 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173539 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 65453MM, MAE65453 | |
| FREIGHTLINER | 1616826000, 1615591000, 1615755000, 1616043000 |
| GABRIEL | 85904, 85043 |
| HALDEX | SA65453 |
| HENDRICKSON | 573247, 573246, 5732413 |
| KYB AMERICA LLC. | KG6416 |
| MERITOR | M85904 |
| NAPA Shocks | 65453 |
| OEM | 1615755000 |
| WORKHORSE | 661532 |
