MONROE 65448 Magnum Shock Absorber - 26.2 in. Extended Length, Rear

$79.99

Limited availability at this price!

In Stock

Get it by Thursday, Jan 29
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65448 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65448 Specifications

Product Attributes

Lower Mount Code L4
Upper Mount Code L4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 16.98 IN
Dust Shield Material Metal
Extended Length 26.2 in
Gas Charged Yes
Lower Mount Type Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL
Parts Pack(s) None
Travel Length 9.22 in
Upper Mount Type Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL
Compressed Length 431.3 MM
Extended Length 665.5 MM
Travel Length 234.2 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173485
VMRS Code 016008003
UNSPSC 25172011

MONROE 65448 Cross References

BrandPart Number
65448MM, MAE65448
ACDELCO50719
BULLDOG HD SHOCKSHD1215-0149
CHEVROLET3166657
Country Coach12B51
Eagle Transit Bus12B51
FLXIBLE TRANSIT BUS63678
GABRIEL85700, 85314, 89425, 87003, 665753
GM3166657
General Motors3166657
HALDEXSA65448
INTERNATIONALAMS700424
KENWORTHK37428PLUS, K37428
KYB341621, 341620
MACK700422MT
MERITORM85700
MONROE VINTAGE74400
MOTOR COACH INDUSTRIES12G51, 12L570, 12J59, 1251GS, 1251G, 12B51G, 12B51GS
Monroe Shocks & Struts74400
NAPA Shocks65448
NAVISTARAMS65448
NEW FLYER3166657
NEWAY57374424
NavistarAMS700424
PETERBILT304176, 301635
Peterbilt0301635, 0304176
TRANSPORTATION PARTS CO.12B51
VOLVO / WHITE / GMC3919975
Volvo GM Heavy Truck3919975

MONROE 65448 Fits Vehicles

  • Peterbilt 362 (1981-1983)
  • Peterbilt 587 (2011-2015)
  • Peterbilt 386 (2006-2016)
  • Peterbilt 372 (1989-1995, 1997)
  • Peterbilt 377 (1990-2001)
  • Peterbilt 384 (2008-2016)
  • Peterbilt 385 (1996-2007)
  • Peterbilt 376 (1988-1992)
  • Peterbilt 375 (1987-1996)
  • Peterbilt 379 (1990-2007)
  • Peterbilt 378 (1990-2007)
  • Peterbilt 357 (1986-2008)
