MONROE 5801 Part Description
Manufacturer
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5801 Specifications
Product Attributes
| Compressed Length | 9.25 IN |
| Compressed Length | 235 MM |
| Extended Length | 14.375 in |
| Extended Length | 365.1 MM |
| Travel Length | 5.125 in |
| Travel Length | 130.2 MM |
| Lower Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.1/2" Pin Length (Hole Center to Center) |
| Lower Mount Type | T-Bar |
| Lower Mount Code | XP5 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01134 |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598040008 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5801 Cross References
| Brand | Part Number |
|---|---|
| 5801ST, GD9Z17D957BPTM | |
| AUTOZONE | TS33-34021B, TS34-32552B, MS34-31751B, TS34-31411B, TS34-31751B |
| AutoZone | MS3431751B, TS3334021B, TS3431411B, TS3431751B, TS3432552B |
| Buick | 22003121, 22003254, 22046423, 22046424, 22046427, 22046428, 22064048, 22064049, 22064104, 22064105, 22064107, 22064179, 22064183, 22064298, 22064299, 22064309, 22064310, 22064311, 22064400, 22064401, 22064433, 22064434, 22064435, 22064436, 22064601, 22064603, 22064630, 22181553, 88945177, 88945188, 88945821, 88945844, 88946013, 88946032, 88946558, 88946562 |
| Cadillac | 22003254, 22046498, 22064046, 22064047, 22064183, 22064311, 22064424, 22064425, 22064426, 22064601, 22065201, 22181553, 22181559, 88946032, 88946562 |
| Chevrolet | 22046423, 22046424, 22046426, 22046427, 22046428, 22046810, 22064040, 22064041, 22064042, 22064043, 22064044, 22064045, 22064100, 22064101, 22064264, 22064265, 22064298, 22064299, 22064400, 22064401, 22064412, 22064413, 22064421, 22064422, 22064433, 22064434, 22064435, 22064499, 22064600, 22064603, 22064618, 22064630, 22064856, 22140148, 22140213, 22181553, 22181559, 88945177, 88945188 |
| Duralast | TS3334021B, TS3431411B, TS3431751B, TS3432552B, MS3431751B |
| FCS | 341517, 341649, 341512 |
| FCS AUTO PARTS | 341517, 341649 |
| Ford | 5U2Z18V125C, 5U2Z18V125VF, E4AZ18125A, E9AZ18124A, E9AZ18124B, E9AZ18124D, E9AZ18124E, E9AZ18124F, E9AZ18125A, E9AZ18125B, E9AZ18125E, E9AZ18125F, E9AZ18125G, E9AZ18125H, F7AZ18124BB, F7AZ18124DB, FOAZ18125A, FOAZ18125B, F0AC18045AA |
| GABRIEL | 69675, 69600, G63375, 69625 |
| KYB | KG4550, KG4503, 344081, 343127, 343128, KG4515, KG5458 |
| KYB AMERICA LLC. | 343127 |
| MasterPro Shocks and Struts | GM105 |
| Mercury | E9AZ18124A, E9AZ18124B, E9AZ18124D, E9AZ18124E, E9AZ18125A, E9AZ18125B, E9AZ18125E, E9AZ18125F, E9AZ18125G, F0AC18045AA, FOAZ18125A, FOAZ18125B |
| Monroe Shocks & Struts | 210114 |
| NAPA Proformer | SH82099 |
| NAPA Shocks | 5801, NS5801 |
| OEM | F0AC18045AA |
| Oldsmobile | 22046424, 22046426, 22046427, 22046445, 22064040, 22064041, 22064298, 22064299, 22064400, 22064401, 4993745 |
| PRT | 192326 |
| Pontiac | 12322219, 22046423, 22046424, 22046426, 22046427, 22064040, 22064041 |
| SACHS NORTH AMERICA | 610003 |
| Sachs | 610003 |
| Sensen | 12140182 |
MONROE 5801 Fits Vehicles
- Pontiac Executive (1967-1970)
- Ford Custom (1957, 1964-1972)
- Cadillac Series 75 Fleetwood (1956-1960)
- Cadillac Series 62 (1956-1960)
- Ford LTD Crown Victoria (1987-1991)
- Toyota Crown (1965-1967)
- Pontiac Star Chief (1961-1966)
- Pontiac Grand Prix (1962-1968)
- Oldsmobile Starfire (1965-1966)
- Oldsmobile Jetstar 88 (1965-1966)
- Oldsmobile Delmont 88 (1967-1968)
- Mercury Park Lane (1958-1960, 1964-1968)
- Mercury Monterey (1957-1974)
- Mercury Montclair (1957-1960)
- Mercury Marauder (1963-1970)
- Mercury Cyclone (1964-1967)
- Lincoln Mark III (1968-1971)
- Ford Mainline (1952-1956)
- Ford Galaxie 500 (1962-1974)
- Ford Galaxie (1962-1967)
- Ford Fairlane (1957-1961)
- Ford Custom 300 (1957-1960)
- Chevrolet Two-Ten Series (1955-1957)
- Chevrolet One-Fifty Series (1955-1957)
- Chevrolet Biscayne (1965-1972)
- Cadillac Series 70 Fleetwood Eldorado (1958)
- Cadillac Series 60 Fleetwood (1956-1960)
- Cadillac Eldorado (1958-1960)
- Buick Centurion (1971-1973)
- Pontiac Laurentian (1971-1974, 1976-1981)
- Mercury Montego (1972-1976)
- Mercury Marquis (1967-1982)
- Mercury Cougar (1974-1979)
- Mercury Grand Marquis (1975-1991)
- Mercury Colony Park (1957-1974, 1987-1991)
- Lincoln Mark VI (1980-1983)
- Lincoln Mark V (1977-1979)
- Lincoln Mark IV (1972-1976)
- Lincoln Continental (1970-1980)
- Ford Torino (1972-1976)
- Ford Thunderbird (1959-1960, 1967-1979)
- Ford Ranchero (1972-1979)
- Ford LTD II (1977-1979)
- Ford Gran Torino (1972-1976)
- Ford Custom 500 (1964-1977)
- Ford LTD (1967-1986)
- Ford Country Squire (1987-1991)
- Pontiac Safari (1987-1989)
- Pontiac Parisienne (1971-1974, 1976-1986)
- Pontiac Grandville (1971-1975)
- Pontiac Grand Safari (1971-1978)
- Pontiac Firebird (1970-1981)
- Pontiac Catalina (1961-1981)
- Pontiac Bonneville (1961-1981)
- Oldsmobile Delta 88 (1965-1985)
- Oldsmobile Custom Cruiser (1971-1992)
- Oldsmobile 98 (1965-1984)
- Chevrolet Impala (1965-1985)
- Chevrolet Caprice (1966-1996)
- Chevrolet Camaro (1970-1981)
- Chevrolet Bel Air (1955-1957, 1965-1975, 1981)
- Cadillac Brougham (1987-1992)
- Cadillac Fleetwood (1977-1986, 1993-1996)
- Cadillac DeVille (1977-1984)
- Buick Roadmaster (1991-1996)
- Buick Riviera (1971-1978)
- Buick LeSabre (1971-1990)
- Buick Estate Wagon (1971-1983)
- Buick Electra (1971-1989)
