MONROE 5601 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5601 Specifications
Product Attributes
| Lower Mount Code | LS50 |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 16.16 IN |
| Dust Shield Material | Metal |
| Extended Length | 25.91 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | P01511 |
| Travel Length | 9.75 in |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 410.5 MM |
| Extended Length | 658.1 MM |
| Travel Length | 247.6 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS50 |
| Upper Mount Code | S4 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598098719 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5601 Cross References
| Brand | Part Number |
|---|---|
| 5601ST, GAMZ2V553AQRM1 | |
| AUTOZONE | TS32-31082B |
| AutoZone | TS3231082B |
| Duralast | TS3231082B |
| FCS | 341623 |
| FCS AUTO PARTS | 341623 |
| GABRIEL | 70028 |
| KYB | 343426 |
| KYB AMERICA LLC. | 343426 |
| MasterPro Shocks and Struts | SC099 |
| Monroe Shocks & Struts | 210050 |
| NAPA Shocks | 5601, NS5601 |
| SENSEN | 32120246 |
| Scion | 4851059765, 4851059785, 4851080263, 4853059795, 4853059815, 4853080195, 4853080293 |
| UNITY AUTOMOTIVE | 259350, 2-259350-001, 4-11920-259350-001 |
MONROE 5601 Fits Vehicles
- Scion xB (2004-2006)
- Scion xA (2004-2006)
