MONROE 37203 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 37203 Specifications
Product Attributes
| Lower Mount Code | LS28 |
| Upper Mount Code | LS52 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 14 IN |
| Dust Shield Material | Metal |
| Extended Length | 21.875 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 7.875 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 1.11/16" Sleeve OAL |
| Compressed Length | 355.6 MM |
| Extended Length | 555.6 MM |
| Travel Length | 200 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598156938 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37203 Part Interchanges
| Brand | Part Number |
|---|---|
| Ram | 68052690AB |
| Dodge | 52109912AD, 52109912AG, 52125307AA, 52125307AB, 68003952AB, 68003954AA, 68003954AB, 68046314AB, 68046314AD, 68052690AB |
| Jeep | 52088650AB, 52088650AE, 52088650AF, 52088655AA, 52088673AC, 52088673AD, 52088673AE, 52125094AC, 52125094AE, 52125603AB, 68031298AC, 68046314AD, 68046318AB, 68052690AB, 68155259AA |
| Ultra Spring Seat | G63844 |
| Gabriel | G63844 |
| KYB | 344404, KG5039 |
| OEM | 52088673AE, 52088673AD, 52125603AB, 52125094AC, 52109912AG, 68052690AB, 52125094AE, 52088673AC |
| FCS Auto Parts | 342557 |
| Unity Automotive | 253020 |
| Sensen | 12140155 |
| AutoZone | TS34-31802B, TS3431802B |
| Rancho | RS5284, RS55284 |
| ACDelco | 530336 |
| Chrysler | 52088673AC, 52088673AD, 52088673AE, 52109912AG, 52125094AC, 52125094AE, 52125603AB, 68052690AB |
| Top Quality | 7837203 |
| NAPA Shocks | 37203, NS37203 |
| FCS | 342557 |
| Duralast | TS3431802B |
| MasterPro Shocks and Struts | JP104 |
MONROE 37203 Fits Vehicles
- Dodge Nitro (2007-2012)
- Jeep Liberty (2002-2012)
MONROE 37203 Cross References
