(888) 312-8812 Login SignupMONROE 34686 Gas-Magnum Suspension Shock Absorber
Tap to view 5 more
MSRP: $92.80
$4499
Save $47.81
Limited availability at this price!
In Stock
Get it by Monday, Dec 15
MONROE 34686 Part Description
Manufacturer
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 34686 Specifications
Product Attributes
| Lower Mount Code | LS26 |
| Upper Mount Code | L1 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 14.25 IN |
| Dust Shield Material | Metal |
| Extended Length | 22.875 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 8.625 in |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Compressed Length | 362 MM |
| Extended Length | 581 MM |
| Travel Length | 219.1 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050700 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34686 Part Interchanges
| Brand | Part Number |
|---|---|
| Ford | 1C3Z18124EA, 1C3Z18125DA, 1C3Z18125DB, 1C3Z18125LA, 1C3Z18125PA, 2C2Z18124CA, 2C2Z18125CA, 2C3Z18125AA, 2C3Z18125BA, 3C3Z18124AA, 3C3Z18124BA, 3C3Z18124CA, 3C3Z18124DA, 3C3Z18124EA, 3C3Z18124FA, 3C3Z18124GA, 3C3Z18124HA, 3C3Z18124JA, 3C3Z18124KA, 3C3Z18124LA, 3C3Z18124MA, 3C3Z18124NA, 3C3Z18124NB, 3C3Z18124PA, 3C3Z18125CA, 3C3Z18125FA, 3C3Z18125GA, 3C3Z18125HA, 3C3Z18125JA, 3C3Z18125JB, 3C3Z18125JC, 3C3Z18125JD, 3C3Z18125JE, 3C3Z18125KA, 3C3Z18125KB, 3C3Z18125KC, 3C3Z18125KD, 3C3Z18125KE, 3C3Z18125LA, 3C3Z18125LB, 3C3Z18125LC, 3C3Z18125LD, 3C3Z18125LE, 3C3Z18125MA, 3C3Z18125MB, 3C3Z18125MC, 3C3Z18125MD, 3C3Z18125ME, F5UZ18124B, F5UZ18125A, F81Z18124AA, F81Z18124AB, F81Z18124AC, F81Z18124AE, F81Z18124AF, F81Z18124AG, F81Z18124AH, F81Z18124AJ, F81Z18124AK, F81Z18124AL, F81Z18124AM, F81Z18124AP, F81Z18124BA, F81Z18124BB, F81Z18124BC, F81Z18124BD, F81Z18124BE, F81Z18124BF, F81Z18124BG, F81Z18124BH, F81Z18124BJ, F81Z18124BK, F81Z18124BL, F81Z18124BM, F81Z18124BN, F81Z18124BP, F81Z18124BQ, F81Z18124BR, F81Z18125CA, F81Z18125CB, F81Z18125CC, F81Z18125CD, F81Z18125CE, F81Z18125CF, F81Z18125CG, F81Z18125CH, F81Z18125CJ, F81Z18125CK, F81Z18125CL, F81Z18125CM, F81Z18125CN, F81Z18125CP, F81Z18125CQ, F81Z18125CR, F81Z18125CS, F81Z18125CT, F81Z18125CV, F81Z18125CW, F81Z18125CX, F81Z18125CZ, F81Z18125DA, F81Z18125DB, F81Z18125DC, F81Z18125DD, F81Z18125DE, F81Z18125DF, F81Z18125DG, F81Z18125DH, 3U2Z18124BAA |
| LTV | 58809 |
| Gabriel | 77809, 58809, 58455, G63809 |
| KYB | 344077, KG5441, KG5043, 344412, 565044, 565090, 565081 |
| Motorcraft | ASHV871, ASH387, ASH408 |
| AutoZone | TS34-31441B, TS3431441B |
| Sachs | 310237 |
| OSC | S5441 |
| FCS Auto Parts | 342502 |
| OEM | 2C2Z18124CA |
| Rancho | RS5267, RS55267 |
| Sensen | 12140126 |
| NAPA Shocks | 76686 |
| AL-KO Xtreme | 813051 |
| Gold Shock Absorber | 9150701 |
| Bulldog HD | HD12140650 |
| FCS | 342501, 342502 |
| NAPA Proformer | SH61655 |
| MasterPro Shocks and Struts | FD109 |
| Duralast | TS3431441B |
MONROE 34686 Fits Vehicles
- Ford E-550 Super Duty (2003)
- Ford E-550 Econoline Super Duty (2002)
- Ford F-550 Super Duty (1999-2004)
- Ford F-450 Super Duty (1999-2004)
- Ford F-350 Super Duty (1999-2004)
- Ford F-250 Super Duty (1999-2004)
MONROE 34686 Cross References
We have 22 alternatives for the 34686 by MONROE:
- MERITOR MG61150
- 34686MM
- MAE34686
- NAVISTAR AMS34686
- MERITOR MG63809
- GABRIEL G63809
- GABRIEL 77809
- KYB 344077
- MOTORCRAFT ASHV871
- GABRIEL 58809
- KYB KG5441
- AUTOZONE TS34-31441B
- SACHS NORTH AMERICA 310237
- FORD 3U2Z18124BAA
- MOTORCRAFT ASH387
- OSC S5441
- FCS AUTO PARTS 342502
- GABRIEL 58455
- MOTORCRAFT ASH408
- OEM 2C2Z18124CA
- HALDEX SA34686
- BULLDOG HD SHOCKS HD1214-0650
