3532059 by MGM BRAKES - Air Brake Chamber - Combination

MGM Brakes 3532059 - Air Brake Chamber - Combination

Part Number
3532059
Manufacturer
MGM BRAKES
Description

Air Brake Chamber - Combination

details

$335.49

2 day lead time

We verify inventory within 1 business day before charging your payment method.
Order online or call us at (888) 312-8812 to confirm. We'll find it for you!
New! No hassle Return Policy details
Free Economy shipping on orders over $499 details
This item will ship about 2 days after the date of purchase
Pay over 3-12 months with Affirm Logo. Learn more

MGM BRAKES part description

General Description

Acids/Liquid Corrosives

Features and Benefits

  • Tamper Resistant Design
  • Molded Nitrile Rubber Push-Rod Air Seal
  • Center Hole Shield
  • Externally Stored Release Bolt
  • Epoxy-Coated Head, Non-Pressure Chamber and Lower Push-Rod Assembly
  • Epoxy Coated Return Spring
  • 360 Aluminum Center Case
  • "Long Life" Power Spring
  • Weatherseal Plug
  • Heavy-Duty Steel Non-Pressure Chamber (8-Gauge Standard on Type 3030 & 3036 Aftermarket Models) (6-Gauge Standard on Type 36 Models)
  • Stroke Alert
  • Polymer Push-Rod Guides
  • Heavy-Duty Nylon Reinforced Diaphragms
  • Heavy-Duty Nylon Reinforced Neoprene Diaphragms (Optional)
  • External Breather Tube
  • Epoxy-Coated Piston & Center Case -Inside & Out
  • Composite Guide -Corrosion Fighter Technology, Type 30 Spring Side Models Only

Technical Specifications

Stroke 2.50" (63.5 mm)
Weight lb (kg) Combination 26.5 lb (12.0 kg)
Weight lb (kg) Single N/A
A 9.86" (250.4 mm)
B 7.52" (191.0 mm)
C 8.31" (211.1 mm)
D 9.18" (233.2 mm)
E 4.75" (120.7 mm)
F 5/8" - 11 UNC (M16 x 1.5 - 6g)
G 5/8" - 18 UNF (M16 x 1.5 - 6g)
Inlets 3/8" - 18 NPTF (M16 x 1.5 - 6H)
X - Min. (aftermarket unit only) 8.00" (203.2 mm)

Product Description

Double Diaphragm Brake Chamber

Features & Benefits

  • Tamper Resistant
  • Long Life Spring
  • Center Hole Diaphragm/Shield
  • Epoxy Coated Head, NPC, Lower Push-Rod Assembly, Return Spring, Piston/Center Case
  • Heavy-Duty Steel NPC
  • Polymer Guides
  • Heavy-Duty Diaphragm
  • Stroke Alert
  • Composite Guide

Product Attributes

Artic Assembly Artic Assembly
Breather Tube Breather Tube
Chamber Type Double Diaphragm Brake
Diaphragm Diameter Rubber IN
Mounting Bolt Length 1.540 IN
Mounting Bolt Thread 5/8-11
Port Size 3/8-18 NPTF
Spring Size 36
Service Size 30
Severe Service Severe Service
Stroke 2.50 IN
UNIT Production

Additional Information

Country of Origin (Primary) US
2
VMRS Code 013004000
