NGK Spark Plugs 5255 - NGK Laser Platinum Spark Plug
- Part Number
- 5255
- Manufacturer
- NGK SPARK PLUGS
- Description
-
NGK Laser Platinum Spark Plug
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
NGK SPARK PLUGS part description
Product Description
NGK Laser Platinum Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction platinum alloy center electrode provides consistent performance
- PLATINUM ALLOY CENTER ELECTRODE: Longer wearing and higher temperature resistance compared to traditional nickel spark plugs
- ROTARY DESIGN: Recessed center electrode surface discharge spark plug designed specifically for rotary engines
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Rotary engines
Product Attributes
| Part Number | BUR9EQP |
| Stock Number | 5255 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Surface Discharge |
| Ground Configuration | Surface Discharge |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Platinum |
| Pre-Gap Size | .055 IN |
| Hex Size | 13/16 IN |
| Insulator Height | 67.00 MM |
| Manufacturer Heat Range | 9 |
| Seat Type | Flat |
| Reach | 21.5 MM |
| Thread Diameter | 14.00 MM |
| Short Style Spark Plug | No |
| Service Number | BUR9EQP |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Ground Electrode Quantity | 0 |
| Hex Size | 13/16" |
| Insulator Height | 2.64 IN |
| Reach | 0.846 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.00 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Surface Gap |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295152553 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
Part Interchanges
Fits Vehicles
- Mazda RX-7 (1984-1991, 1993-1995)
Headquartered in Wixom, Michigan, NGK® is a global leader in the design and manufacture of spark plugs for virtually every automotive and commercial vehicle application. It has grown immensely since its inception in 1936 with the expansion of its ignition product line and the introduction of its technical sensor and vehicle electronics line. NGK partners with OEMs and uses only the latest cutting tools to ensure each NGK product meets OE specifications for exact fit, form, and function. With world-class quality and engineering, NGK’s expertise goes beyond manufacturing the most reliable spark plugs for the automotive industry but also providing the best customer service possible.
