MONROE 34530 Part Description
Manufacturer
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34530 Specifications
Product Attributes
| Compressed Length | 9.75 IN |
| Compressed Length | 247.6 MM |
| Extended Length | 14.02 in |
| Extended Length | 356.1 MM |
| Travel Length | 4.27 in |
| Travel Length | 108.5 MM |
| Lower Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/16" Pin Length (Hole Center to Center) |
| Lower Mount Type | T-Bar |
| Lower Mount Code | XP4 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01136 |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598112194 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34530 Cross References
| Brand | Part Number |
|---|---|
| 34530MM, FT4Z5806024AA | |
| ACDELCO | 530450, 520408 |
| ACDelco | 5601042, 560973 |
| AL-KO Xtreme | 813102 |
| AUTOZONE | TS34-31581B |
| AutoZone | TS3431581B |
| Autopart International | 2701424146 |
| BILSTEIN | 24187435 |
| Bulldog HD | HD12140867 |
| Chevrolet | 19257310, 20956369, 20956377, 20956378, 20956379, 20956380, 23296352, 23296353, 25751135, 25751136, 25751137, 25751138, 25856173, 25856175, 84020664, 84020665, 84020666, 84020667, 84020668, 84020673, 84040778, 84040779, 84040780, 84301663, 84301664, 84301665, 84301666, 84301668, 84303233, 84303234, 88982650, 88982652 |
| Duralast | TS3431581B |
| FCS | 341596, 348006 |
| FCS AUTO PARTS | 341596 |
| GABRIEL | G63895, G63893, 61685 |
| GMC | 19257310, 20956369, 20956377, 20956378, 20956379, 20956380, 23296352, 23296353, 25751135, 25751136, 25751137, 25751138, 25856173, 25856175, 84020664, 84020665, 84020666, 84020667, 84020668, 84020673, 84040778, 84040779, 84040780, 84301663, 84301664, 84301665, 84301666, 84301668, 84303233, 84303234, 88982650, 88982652 |
| General Motors | 19257310, 20956369, 23296352, 84020673, 84040778, 84303233, 84303234, 88982652 |
| KYB | 554356, 349046, 344481, KG5780, KG5040, 341343, 3440174, 3440193 |
| MasterPro Shocks and Struts | GM112 |
| Monroe Shocks & Struts | 32362, 210450, 34530 |
| NAPA Shocks | 76530, PNS94257 |
| OEM | 20956369, 84303233, 84303234, 19257310, 88982652, 84020673, 84040778, 23296352 |
| OSC | S349046 |
| PM Auto | PM6001027 |
| PRT | 170195, 173860 |
| Sachs | 030204, 30204 |
| Sensen | 12140176 |
| TRQ | SBA72157 |
| TRW | JGT4008S |
| UNITY AUTOMOTIVE | 2-211140-001, 4-211140-251220-001, 211140 |
| Ultra Spring Seat | G63893 |
| Unity | 211140 |
MONROE 34530 Fits Vehicles
- Roadtrek Versatile (2013-2017)
- Roadtrek Popular (2013-2019)
- Jayco Redhawk SE (2018-2023)
- Itasca Spirit (2006-2008)
- Itasca Impulse (2007-2009)
- Forest River Sunseeker (2007-2021)
- Forest River Forester (2008-2019)
- Econoline Sidekick (2013-2015)
- Coachmen Leprechaun Premier (2019-2020, 2022)
- Winnebago Outlook (2006-2008)
- Winnebago Spirit (2003-2004, 2006)
- GMC Savana 4500 (2009-2025)
- Chevrolet Express 4500 (2009-2025)
- GMC Savana 3500 (2003-2025)
- GMC Savana 2500 (2003-2025)
- Chevrolet Express 2500 (2003-2025)
- Chevrolet Express 3500 (2003-2025)
