EUCLID part description

Wheel End Hardware - Wheel Stud, Single End, LH

Product Description

STUD

Product Attributes

Body Diameter 0.787 in./0.780 in.
Body Length 1.44 in.
Brand Euclid
Grade 8
Head Diameter 1.35 in.
Head Style Round
Head Thickness 0.28 in.
Length From Under Head 3 25/32 in.
Metric Thread Size 3/4-16 UNF-2A
Notes Stepped Body Diameter
OEM ConMet 102281
Pallet Quantity 1000
Serration Serrated
Serration Diameter 0.820 in.
Serration Length 0.38 in.
Thread 3/4"-16
Thread Diameter 0.75 in.
Thread Direction LH
Thread Length 1.88 in.
Threads Per Inch 16
Type Headed
Weight .55

Euclid® is a world leader in the production of precision-engineered replacement parts for buses, trailers, as well as light-, medium- and heavy-duty trucks. This brand takes great pride in its products that meet and even exceed O.E.M. quality standards. Officially a part of Meritor since January 1999, Euclid remains the same despite all the changes the company has been through. When customers receive Euclid products, they know they are getting far more than ordinary replacement parts. Instead, they are getting the best replacement parts made today from a company they can trust. Euclid is a company that's continuously improving with technology to do a job the right way because it is the only way it knows how.
