Haldex DA34135 - PURest™ Air Brake Dryer - New, With Heater, 12V Metri-Pack Male Heater With bracket
$51049
MSRP: $824.34
Save: $313.85
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
HALDEX part description
Product Description
PURest™ Air Dryer, 12V, Kit
Features & Benefits
- Made with a multi-treatment cartridge that employs five stages of cleaning to ensure dry system air
- Offers ease of installation as it comes with a universal mounting bracket
- Can fit Pure Air Plus, DRYest, AD type, and SS type air dryer bolt patterns
- Designed with a built-in heater to prevent dryer freezing and damage
- Built to offer integrated turbo protection
- Made to fit 17-3/4" x 9-3/4" x 9-1/2" envelope
- For desiccant cartridge change, the product includes 1/2" clearance
Haldex PURest™ Air Brake Dryer
Prevent air-line freeze-ups with the Haldex PURest™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.
Product Attributes
Airflow Rate | 34 SCFM |
Dessicant Cartridge Weight | 3.5 lbs. |
Drying Stages | 5 |
Freight Class | 70 |
Heater Included | Yes |
Heater Voltage | 12V |
Integrated Turbo Protection Pressure Drop | 2 PSI @ 15 SCFM/120 PSI |
Internal Purge Volume | 210 cu. in. |
Maximum Working Pressure | 150 PSI |
Maximum Working Temperature | 175°F |
Minimum Working Temperature | -40°F |
Mounting Bracket Included | Yes |
New Or Remanufactured | New |
Notes | 12V Metri-Pack Male Heater With bracket |
Safety Relief Pressure | 175 PSI |
Secondary Pressure Protection | 235 PSI |
Series | PURest™ |
Wattage | 95 Watts |
Additional Information
Country of Origin (Primary) | MX |
Harmonized Tariff Code (Schedule B) | 8421398015 |
Harmonized Tariff Code (HTS) | 8421398015 |
Remanufactured Part | N |
Warranty Distance | 100000 |
Warranty Distance UOM | MI |
Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
Warranty Time | 12 |
Warranty Time UOM | MO |
UPC | 00767653329871 |
VMRS Code | 013010013 |
Part Interchanges
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.California Proposition 65 Warning
