HALDEX part description

Product Description

Dryer Assembly 12V, Air

Features & Benefits

  • Made with a multi-treatment cartridge that employs five stages of cleaning to ensure dry system air
  • Offers ease of installation as it comes with a universal mounting bracket
  • Can fit Pure Air Plus, DRYest, AD type, and SS type air dryer bolt patterns
  • Designed with a built-in heater to prevent dryer freezing and damage
  • Built to offer integrated turbo protection
  • Made to fit 17-3/4" x 9-3/4" x 9-1/2" envelope
  • For desiccant cartridge change, the product includes 1/2" clearance

Haldex PURest™ Air Brake Dryer

Prevent air-line freeze-ups with the Haldex PURest™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.

Product Attributes

Airflow Rate 34 SCFM
Dessicant Cartridge Weight 3.5 lbs.
Drying Stages 5
Freight Class 70
Heater Included Yes
Heater Voltage 12V
Integrated Turbo Protection Pressure Drop 2 PSI @ 15 SCFM/120 PSI
Internal Purge Volume 210 cu. in.
Maximum Working Pressure 150 PSI
Maximum Working Temperature 175°F
Minimum Working Temperature -40°F
New Or Remanufactured New
Safety Relief Pressure 175 PSI
Secondary Pressure Protection 235 PSI
Series PURest™
Wattage 95 Watts

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8421398015
Harmonized Tariff Code (HTS) 8421398015
Remanufactured Part N
Warranty Distance 100000
Warranty Distance UOM MI
Warranty Special See Haldex Aftermarket Product warranty Policy (L20221W).pdf
Warranty Time 12
Warranty Time UOM MO
UPC 00767653283159
VMRS Code 013010252

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.

HALDEX DA34100 Cross Reference

We have 4 alternatives for the DA34100 by HALDEX:
