Gates G20179-0808 - 8GS 8FJX90S
$3299
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Female JIC 37 Flare Swivel - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250 Deg. F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
Product Attributes
| Coupling Description | GlobalSpiral Female JIC 37 Flare Swivel - 90 Bent Tube |
| Industrial Description | 8GS-8FJX90S |
| Thread Size | 3/4-16 |
| Inside Diameter | .5 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Nut Hex Size | .875 IN |
| Drop Length | 1.14 IN |
| Cut-Off Length | 1.91 IN |
| Length | 3.39 IN |
| Inside Diameter | 12.7 MM |
| Drop Length | 29 MM |
| Cut-Off Length | 48.6 MM |
| Length | 86.1 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053310702 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
