GATES 70600 Global G1 1-Wire Braid Hose - SAE 100R1 Type S

Name: Gates 70600 Global G1 1-Wire Braid Hose - SAE 100R1 Type S
SKU: 70600
Price: 5.18 USD
Availability: OutOfStock

$5.18

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

GATES 70600 Part Description

Global G1 1-Wire Braid Hose - SAE 100R1 Type S

Use with Field Attachable Type T [G27 Series], GlobalSpiral [G20 Series], GlobalSpiral Plus [G22 Series], MegaCrimp [G25 Series], Power Crimp or Stainless Steel Braid Couplings [G17 Series]
Meets Flame Resistance Acceptance Designation MSHA 2G
Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)

Product Type	Global G1 1-Wire Braid Hose - SAE 100R1 Type AT
Industrial Description	4G1XREEL
Type	Hydraulic Hose
Hose Pressure Description	Medium Pressure
Maximum Working Pressure	3275 PS
Burst Pressure	13100 PS
Temperature Rating	-40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Length	400 FT
Dash Size	4
Inside Diameter	.25 IN
Outside Diameter	.53 IN
Bend Radius	4
Tube Description	Black, Oil-Resistant, Synthetic Rubber
Hose Material	Nitrile - Type C
Reinforcement Material	One Braid, High-Tensile Steel Wire
Cover Material	Synthetic Rubber - Nitrile/PVC - Type C2
Cover Type	Type C2 - Flame, Oil & Abrasion Resistant
Cover Color	Black
Coupling Recommendation	Field Attachable T, MegaCrimp, Stainless Steel B
SAE Standard	100R1
EN Standard	853 1SN
ISO Standard	1436 1SN R1

Harmonized Tariff Code (Schedule B)	4009210000
Country of Origin (Primary)	MX
Stock Status	S
UPC	00072053211054
VMRS Code	059032029
UNSPSC	40142020
