(888) 312-8812 Login SignupGATES 70486 PF HOSE
$949
Limited availability at this price!
In Stock
Get it by Friday, Feb 20
GATES 70486 Part Description
Manufacturer
Product Description
Global M3K Mega3000 Hose - SAE 100R17
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], MegaCrimp Couplings [G25 Series], Power Crimp Couplings (-3 Only) and Stainless Steel Braid Couplings [G17 Series]
- Provides bend radius up to 1/3 of the SAE specification and greater flexibility for easier routing
- Tested to industry-leading 600,000 impulse cycles
- XtraTuff hose lasts up to 25 times longer than standard hose
- MegaTuff hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Rated at 3250 PSI working pressure
- Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
GATES 70486 Specifications
Product Attributes
| Product Type | Global M3K Mega3000 Hose - SAE 100R17 |
| Industrial Description | 6M3KXREEL |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 3250 PS |
| Burst Pressure | 13000 PS |
| Temperature Rating | -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C) |
| Length | 330 FT |
| Dash Size | 6 |
| Inside Diameter | .375 IN |
| Outside Diameter | .63 IN |
| Bend Radius | 2 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | One Braid, High-Tensile Steel Wire |
| Cover Material | Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline |
| Cover Type | Type C2 - Flame, Oil, Abrasion & Weather Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSpiral, MegaCrimp, Stainless Steel B |
| SAE Standard | 100R17 |
| EN Standard | 857 1SC |
| ISO Standard | 18752 Grade B, 11237 R17 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053318630 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 70486 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | FC639-06, FC639-06RL, GH683-06, GH681-06, GH681-6, GH683-6 |
| Dayco | 014756 |
| Eaton | GH681-6 |
| Goodyear | GCP3-06X250, GR17-06X250RL, GR18-06X250 |
| N/A | 04029886, EC118-06 |
| NAPA | 70486 |
| Parker | 387-6 |
| Weatherhead | H11406250R, H11406500R, H14506250R, H14506500R, H14606250R, H11406-250R, H14606-250R, H11406-500R |
