Name: Weatherhead H14506-250R Eaton Weatherhead H145 Series Rubber Hydraulic Braided Hose
SKU: h14506250r
Price: 1622.5 USD
Availability: InStock

WEATHERHEAD part description

California Proposition 65 Warning

WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)

Abrasion Resistance	Standard
Application	Construction.
Bend Radius Min	2.5 inch
Burst Pressure	12180 psi
Color	Black
Construction	1 Ply Braid
Cover Material	Neoprene
Dash Size	-6
Factory Crimp	Yes
Impulse Cycle Life	200000 cycle
InsIDe Diameter	0.375 inch
Lay Line Style	Ink Jet
Length Configuration	50, 250, 500
OutsIDe Diameter	0.64 inch
Package Form	Reel
Qualified Hose Fittings	U, S, Z
Reinforcement Material	Wire
Tube Material	Nitrile
Tube Wall Thickness	0.1328 inch
Working Pressure	3045 psi
Working Temperature Max	250 degree Fahrenheit
Working Temperature Min	-40 degree Fahrenheit

Features & Benefits

Maximum durability under harsh operating conditions
Robust construction able to withstand highest pressures
System engineered to extend hose assembly life

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
