GATES 6848 Part Description
Manufacturer
Product Description
PoweRated FHP Medium Horse-Power V-Belt
Application Summary
Ace Hardware, 72428, , Trans.
Features & Benefits
- Designed with distinct green color bareback construction for smooth clutching on shock loaded, backside idler-driven equipment to ensure high crack resistance
- Low, aramid tensile cord positioned in a thin profile gives extreme flexibility and limited stretch with extraordinary strength and durability
- Meets RMA oil and heat-resistant standards, but not for static conductivity
- Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
- Note: Gates PoweRated V-belts can be substituted for equivalent sizes of FHP low horsepower Gates Truflex V-belts
GATES 6848 Specifications
Product Attributes
| Type | FHP Medium Horse-Power V-Belt |
| Cross Section Designation | 4L |
| Angle | 37 |
| Strand Quantity | 1 |
| Top Width | .5 in |
| Outside Circumference | 48 in |
| Effective Length | 48.18 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Aramid |
| Top Width | 13 mm |
| Outside Circumference | 1219 mm |
| Effective Length | 1224 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053004533 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 6848 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 02017, 03527, 0387116, 054048, 0540480, 06209, 1009668, 1009800, 10101500, 102227, 1049321, 10711, 11034, 1221K, 148, 15D4015H15, 17471, 1816053, 18459, 200371, 205048, 20A32148, 2148, 222398, 23890, 2554, 26016, 262141, 26220, 27202P, 27518P, 285341, 286102, 3033918, 31148, 31713, 35616, 360248, 407A53, 4158, 4548B, 4695A1371, 492232, 4A9, 5061615, 5132, 532248, 560113, 5H56784A, 5H57964A480, 600115A, 647012, 69S2759, 75129, 75148, 902275, 90758, 95381, AB197, B168A, B3085, B4220, B4280640, BT100, BT106, C4A104, JP2828, K27B44, K810236317, KK5705475AR63, KR20AC048, M1801413, M291, P3648, P8128, PB128, R10849, S1193, S863500, 07956, 079596, 2480W, 60B46, 70675232, 72383, 9528, B23D, DA4L480, ST22 |
| ACDelco | 4L480, 4L480P |
| Aircap | 1190 |
| Allis Chalmers | 2025893, 2025895 |
| Ariens | 072062, 34X91, 72062, 72091 |
| Atlas Press Co | 1250126 |
| BF Goodrich | 1480 |
| Big Wheels | 104475 |
| Bolens | 1714286, 1742629 |
| Borg Warner | 02810703000 |
| Brown Trucks | E-200-002 |
| Bryant Mfg | 94015, 94006 |
| Bush Hog | S3304 |
| CARQUEST | 2480, 6848 |
| CONTINENTAL AG | 84480, 4L480, 84180 |
| Campbell Hausfeld | BT0028, BT28 |
| Dayco | 1M048, 4L480, 48X480, L448, P448 |
| Delta International | 51009 |
| Demco | 6L150 |
| Dexter Co | 9040073001 |
| Durkee-Atwood | 48-480, XDV48-480 |
| Engineering Products | RTB3 |
| Food Machine | 1108481, 1704403, 1714286 |
| Frigidaire | 5433778, 5870146, 5927290, EA72058 |
| Gardner Denver | 13C58 |
| General Electric | 559711, K5705475AG29, K5705475AJ21, K5705475AN32, WE12X4 |
| Gilmer | 3480 |
| Gilson | 208527, 229604 |
| Goodall | W00666 |
| Goodyear | 4L480, 74480, FA48, 48480, 84475, 84480, 4LK480 |
| Gould | 80705117 |
| Grainger | 4L480 |
| Gravely | 26114, 26127 |
| Hahn | 308437, 308442, 308462 |
| Hamilton | 1114 |
| Heil | MX3419 |
| Homelite | 108428 |
| Jacobsen | 331672, 331847 |
| Jari Division | F121 |
| John Deere | J15342, LG48480, TY4397, M44483 |
| Kelvinator | 1080921, AR415, AR415B |
| L Series | 4L480 |
| Lawn Boy | 165120, 606508 |
| Locke | 3280 |
| MBL Three Stars | 4LK480 |
| MTD Products | 7540200, 7540276, 7540352, 754200, 754276, 9540352 |
| Metric | 13R1220, 13RL1220 |
| Montgomery Ward | P151038 |
| Mopar | B4L-480 |
| Murray | 12534, 20556, 37X2, 37X28, 75121 |
| NAPA Belts/Hose | 4L480, 4L480W |
| Noma | 385 |
| Oregon | 75-748, 75-448 |
| PIX | A-4L480 |
| Penneys | 6128B |
| Power Lawnmower Part | 109-106 |
| Prime-Line | 7-07856, 7-4H480 |
| Reliance Electric | 108032 |
| Rockwell International | 35148, 925010112231 |
| Root | 12278 |
| Rotary Lifts | 12-5081, 123431, 12-7491, 123763 |
| Rotohoe | 2480, 5065A |
| Rototiller | 129X |
| Sanborn | 0070020 |
| Sears | 1648, 304480, 25654, STD304480, STD324480 |
| Sensation | 153401 |
| Silver Streak | 75-748, DB4L480, 75-448 |
| Simplicity | 108248, 1602969 |
| Snapper | 14503, 15403, 15409 |
| South Bend Lathe | CE4548B |
| Speedex | 3916848 |
| Stens | 248-048 |
| Sunshine Mower | 3400 |
| Thermoid | 4H480 |
| Toolkraft | 1928 |
| Toro | 71410, 74226, 74228 |
| U.S. | 5631 |
| U.S. Government | 3030005283767, 3030009431031, MS392424L480 |
| Universal Sewing | 13658 |
| Walton | 8022 |
| Westinghouse | Q62141, Q62142, Q62148 |
| Wheel Horse | 110420 |
| Whirlpool | 91261 |
| White | 9003007 |
| X Series | 8X482 |
| Yazoo | 205448 |
