(888) 312-8812 Login SignupGATES 26506 Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
$6999
Limited availability at this price!
In Stock
Get it by Thursday, Jul 23
GATES 26506 Part Description
Manufacturer
Product Description
Green Stripe Heavy-Duty Vulco-Flex Coolant Hose
Application Summary
Austin-Western, 720, Detroit Diesel 6V-53 Diesel, Upper - Left Side
Features & Benefits
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Built-in steel spiral wire allows for medium sized curves without kinking or collapsing
- EPDM tube and Neoprene cover for extended service life
- Polyester fabric-ply reinforcement vulcanizes into shape without unnecessary strain on connections
- Resistant to heat, oil and ozone
- Performs to SAE 20R5 Type EC Class D-2 specifications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Caution: Do not use for fuel or oil transfer applications
GATES 26506 Specifications
Product Attributes
| Centerline Length | 23.5 IN |
| End 1 Inside Diameter | 1.75 in |
| End 2 Inside Diameter | 2 in |
| Material | EPDM, Steel |
| Molded | No |
| Centerline Length | 597 MM |
| End 1 Inside Diameter | 44 MM |
| End 2 Inside Diameter | 51 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Stock Status | S |
| UPC | 00072053064766 |
| VMRS Code | 042004061 |
| UNSPSC | 40142000 |
GATES 26506 Cross References
| Brand | Part Number |
|---|---|
| 42840135 | |
| <Unknown> | 3049333 |
| ACDelco | 31705 |
| Allis Chalmers | 1184602 |
| CARQUEST | 26506 |
| CONTINENTAL AG | 528231 |
| Continental Belt | 528231 |
| Dayco | 1324HD, 82051, 82051GL, M82 |
| Ford | F3HZ 8260 A |
| General Motors | 2485924, 2487364, 2490273, 700122, 8865524, 8865535 |
| Goodyear | 528231 |
| Motorcraft | KCD-234, KM-2074 |
| NAPA Belts/Hose | FM125 |
GATES 26506 Fits Vehicles
- Hino GC17 (1990-1991)
- Hino FD17 (1988-1991)
- Hino FF17 (1985-1991)
- Hino FE17 (1985-1991)
