(888) 312-8812 Login SignupFRAM CH6004 Motorcycle Full-Flow Lube Cartridge
Tap to view 8 more
$11.46
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FRAM CH6004 Part Description
FRAM CH6004 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 2.234 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | Yes |
| Bypass Relief Valve Setting | 8-10 PS |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 0.765 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 2.094 IN |
| O-ring (1) Outside Diameter | 2.296 IN |
| O-ring (1) Thickness | 0.094 IN |
| O-ring (2) Inside Diameter | 0.281 IN |
| O-ring (2) Outside Diameter | 0.469 IN |
| O-ring (2) Thickness | 0.094 IN |
| O-ring Inside Diameter | 2.422 IN |
| O-ring Outside Diameter | 2.531 IN |
| O-ring Thickness | 0.078 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.172 in |
| Outer Diameter Top | 2.172 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.765 in |
| Torque Nut | No |
| Washable | No |
| Bottom Inside Diameter | 0.765 IN |
| Outside Diameter Top | 2.172 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100381354 |
| UNSPSC | 15121501 |
FRAM CH6004 Cross References
| Brand | Part Number |
|---|---|
| Aprilia | AP8520017 |
| BALDWIN | P40089 |
| BIG A | 96935, 96936 |
| CANADIAN TIRE | 27-5508-2 |
| CARQUEST | 89935, 89936 |
| CHAMP | P7004 |
| EMGO | 10-29100, 10-79100 |
| HASTINGS | LF583 |
| HiFlo | HF145 |
| K&N | KN-145 |
| LUBER-FINER | P7004 |
| MANN-HUMMEL FILTERS | ML16804 |
| Master Parts | P-305 |
| NAPA | 4935, 4936 |
| PREMIUM GUARD | MG145 |
| Purolator | ML16804, ML16805 |
| STP | P7004 |
| WIX FILTERS | WIX FILTERS, 24935 |
| Warner | P7004 |
| Wix | 24935 |
| Yamaha | 2H0-13440-90, 4X7-13440-01, 4X7-13440-01-00, 4X7-13440-90, 4X7-13440-90-00 |
FRAM CH6004 Fits Vehicles
- Yamaha XV920 Virago (1982-1983)
- Yamaha XV920R Seca (1981-1982)
- Yamaha YFM700R Raptor 700R SE (2018-2025)
- Yamaha YFM700R Raptor 700R (2018-2025)
- Yamaha SR400 (2016, 2018)
- Yamaha YFM700 Raptor 700 (2015-2025)
- Yamaha XVS650AT V Star Silverado (2010)
- Yamaha XVS650A V Star Classic (2010)
- Yamaha XVS650 V Star Custom (2010-2011, 2013-2016)
- Yamaha XVS1100 V Star 1100 Custom (1999-2009)
- Yamaha XV750 Virago (1981-1983, 1988-1997)
- Yamaha XV1100 Virago (1986-1999)
- Yamaha XV1000 Virago (1984-1985)
