WABCO 4802050100 - Air Brake Relay Valve - 3/2, 24V, 147.94 psi Max, 4 x M8 Mount
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
WABCO part description
Product Attributes
| Size | 151 x 101 x 132 |
| Calculated Volume (dm³) | 2.0131 |
| Weight | 2.5529 |
| Voltage | 24 V |
| Temperature Range | -40°C to +80°C |
| Max. operating pressure | 147.94 psi |
| Max. operating pressure | 147.94 psi |
| Mounting | 4x M8 |
| Distance between bolts | 75x75 mm |
| Port thread 3 | Exhaust |
| Protection class | IP 66 / IP 69K |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Port Thread 41 | M16 x 1.5 JED-388 |
| Thread | Voss 230 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port Thread 42 | M16 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED - 152 |
| Port Thread 43 | M16 x 1.5 JED-388 |
WABCO 4802050100 Cross Reference
We have 1 alternatives for the 4802050100 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
