(888) 312-8812 Login SignupCENTRIC 120.22022 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 1 more
$208.82
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.22022 Part Description
Manufacturer
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.22022 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Pillar |
| Hat Id [cntrc] Mm | 164.900 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 15.600 |
| Hat Id [cntrc] In | 6.492 |
| Weight [cntrc] Lbs | 34.350 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.235 IN |
| Discard Thickness | 31.000 MM |
| Nominal Thickness | 1.339 IN |
| Nominal Thickness | 34.000 MM |
| Hat Finish | Painted |
| Overall Height | 62.100 MM |
| Overall Height | 2.445 IN |
| Outside Diameter | 380.000 MM |
| Outside Diameter | 14.961 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.110 IN |
| Center Hole Diameter | 79.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.591 IN |
| Stud/Lug Hole Diameter | 15.000 MM |
CENTRIC 120.22022 Cross References
| Brand | Part Number |
|---|---|
| BREMBO | 09.C820.11 |
| NEOTEK | 1067588GF |
| RAYBESTOS | 980926, 980926R |
CENTRIC 120.22022 Fits Vehicles
- Land Rover Range Rover (2013-2022)
- Land Rover Range Rover Sport (2010-2019, 2021-2022)
- Land Rover Defender 130 (2023-2025)
- Land Rover Defender 110 (2021-2025)
- Land Rover Discovery (2021-2025)
- Land Rover Defender 90 (2021-2025)
