(888) 312-8812 Login SignupCENTRIC 120.58005 Centric Premium Brake Rotor
Tap to view 4 more
$11399
Limited availability at this price!
In Stock
Get it by Tuesday, Jun 30
CENTRIC 120.58005 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.58005 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.500 |
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] In | 8.098 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 205.700 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 18.700 |
| Discard Thickness | 0.492 IN |
| Discard Thickness | 12.500 MM |
| Nominal Thickness | 14.000 MM |
| Nominal Thickness | 0.551 IN |
| Hat Finish | Painted |
| Overall Height | 2.508 IN |
| Overall Height | 63.700 MM |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Center Hole Diameter | 2.835 IN |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.669 IN |
| Stud/Lug Hole Diameter | 17.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890712817 |
CENTRIC 120.58005 Cross References
| Brand | Part Number |
|---|---|
| ADVICS | P6R220U |
| N/A | 120.58005, BD180435, BD180435E, E125-63-010, BR90095202, 43529, 63909L, 43178, YH321093, 53061G, 0053409711, 53409711, 52124763AB, 52124763AC, 52124763AD, 72163, 850237, 90042004, E12563010 |
| NEOTEK | 107327GF |
| Neotek Premium Drums and Rotors | 107327GF |
| PRONTO | BR90095202 |
| RAYBESTOS | 780867, 780867FZN, 780867R, 780867R2 |
| Raybestos Brakes | 780867, 780867FZN, 780867R |
| WAGNER | BD180435E, BD125218, BD180435 |
CENTRIC 120.58005 Fits Vehicles
- Jeep Grand Cherokee (2011-2020)
- Dodge Durango (2011-2020)
