CENTRIC 120.86012 Part Description
Manufacturer
Product Description
Centric Air Disc Brake Rotor Meritor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
CENTRIC 120.86012 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | U Shaped |
| Weight [cntrc] Kgs | 30.230 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 66.500 |
| Nominal Thickness | 1.772 IN |
| Nominal Thickness | 45.000 MM |
| Overall Height | 6.280 IN |
| Overall Height | 159.512 MM |
| Outside Diameter | 419.354 MM |
| Outside Diameter | 16.510 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 18.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 215.500 MM |
| Center Hole Diameter | 8.484 IN |
| Mounting Bolt Hole Circle Diameter | 10.492 IN |
| Mounting Bolt Hole Circle Diameter | 266.500 MM |
| Mounting Bolt Hole Diameter | 0.625 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 00805890652632 |
CENTRIC 120.86012 Cross References
| Brand | Part Number |
|---|---|
| 0077303, 77303 | |
| MERITOR | 23123615002 |
| N/A | E125-91-017, 41315, 23123615096, 123615, E12591017, 23123615002, 0077303, 77303 |
CENTRIC 120.86012 Fits Vehicles
- Blue Bird Wanderlodge (2003-2007)
