Cole Hersee 75920 - Master Disconnect Switch - Battery Master Switch, SPST, On/Off, 300A at 12V DC
- Part Number
- 75920
- Manufacturer
- COLE HERSEE
- Description
-
Master Disconnect Switch - Battery Master Switch, SPST, On/Off, 300A at 12V DC
details
$5249
MSRP: $73.48
Save: $20.99
In stock
limited availability at this price!
COLE HERSEE part description
Specifications: | |
Configuration | SPST |
Modes | On/Off |
Application | Heavy Duty, Mining |
Approvals | IP67 Rated, SAE J1455 |
Protects from hazards during vehicle servicing,and can be locked-out or tagged-out. Provides an effective emergency power cutoff. Can be used in both positive or in negative path applications. Waterproof and dustproof to ip67 (immersible). Switch can be located in the best location, regardless of environment. Composite engineered polymer housing will not rust or corrode. Tested per SAE 1455 for salt corrosion. Large red knob is easy to operate with gloved hands; 90º switch travel makes it easy to identify the switch position. Built-in lockout satisfies osha requirements for an energy isolation device. Attractive styling suitable for visible mounting close to operator. Large divider on base prevents accidental shorting of high energy cables. Fits standard Master Disconnect mounting pattern. Knob is secured in place with a set screw.
- High amperage capacityThe current handling capability or rating of a switch. Alternatively refers to the amount of charge a component (like a capacitor) can hold - measured in Farads.: 300A at 12V DC.
- Protects vehicles against tampering, theft and batteryA collection of voltaic cells grouped together to provide higher voltage and/or higher current than a single cell. The battery is a common DC power source, especially for vehicles or equipment that is used remote from the domestic power supply.
- Emergency vehicles and utility vehicles often have dual battery systems because of added power demand. Such systems necessitate the use of a Battery Selector Switch or a Low Voltage Disconnect Switch. drain.
- Protects from hazards during vehicle servicing,and can be locked-out or tagged-out. Provides an effective emergency powerElectrical energy measured according to voltage and current (normally watts). Power in watts equals volts times amperes for DC circuits.
- Can be used in both positive or in negative path applications.
- Waterproof and dustproof to ip67IP numbers refer to INGRESS PROTECTION of a device against ingfress of dust or liquid. A switch with a rating of IP67 will resist spraying with a high pressure hose. A switch with IP68 is even more resistant. These are the two most useful numbers when you're considering spec'ing a switch. (immersible).
- Switch can be located in the best location, regardless of environment.
- Composite engineered polymer housing will not rust or corrode.
- Tested per SAE 1455 for salt corrosion.
- Large red knob is easy to operate with gloved hands; 90º switch travel makes it easy to identify the switch position.
- Built-in lockout satisfies oshaThe US federal Occupational Safety and Health Administration at osha.gov OSHA's mandate is to improve health and safety in the workplace by enforcing standards. Such standards encourage the use of Master Disconnect Switches (like 75920) that can be locked-out or tagged-out. requirements for an energy isolation device.
- Attractive styling suitable for visible mounting close to operator.
- Large divider on base prevents accidental shorting of high energy cables.
- Fits standard Master Disconnect mounting pattern.
- Knob is secured in place with a set screwA threaded fastener typically used to hold a sleeve, collar or gear on a shaft to prevent relative motion. You can find it on several Cole Hersee brand knobs, many of which have a metal sleeve with set screw to insure reliable operation. A set screw normally does not have a head. Various socket types are provided to allow the set screw to be rotated. These types include hexagon socket, fluted socket, screwdriver slot and square head. .
Property | Value |
---|---|
Installation | fits standard Master Disconnect Switch hole |
Operating temperature range | -40degC to +85degC |
Corrosion test | 96hours salt spray test to ASTM standard |
Vibration test | 10-500Hz to SAE J1455 |
Shock test | To SAE J1455 |
Battery terminals | 3/8" - 24 70-90 in-lbs (8-10Nm) |
Mounting hardware | 3/4" - 16 18ft-lbs max (24.4Nm) |
Operating voltage | 6V min 36V max |
Continuous current | 12V 300A max, 24V 250A max, 36V 200A max |
Intermittent current | 12V 1000A 90sec On 5 min Off |
Intermittent current | 12V 1500A 60sec On 5 min Off |
Intermittent current | 12V 2000A 30sec On 5 min Off |
Intermittent current | 12V 3000A 15sec On 5 min Off |
Cole Hersee Battery Disconnect Switch
The Cole Hersee 75920 Series battery disconnect switch provides reliable power cut-off for heavy-duty vehicles. Its high amperage capacity makes it suitable for either high side or low side applications.
Features & Benefits
- Waterproof and dustproof construction that complies with IP67 regulations
- Housing made of composite polymer housing that will not rust or corrode
- Tested for salt, calcium chloride, and magnesium chloride resistance according to SAE 1455 specifications
- Large divider on base protects against accidental shorting of high energy cables
- Large bright red knob can be operated with gloved hands
COLE HERSEE 75920 Cross Reference
We have 2 alternatives for the 75920 by COLE HERSEE:
Cole Hersee® is highly valued in the heavy duty truck industry. It is a leading manufacturer of heavy-duty battery master switches that are widely used as OE equipment by leading heavy-duty vehicle manufacturers. These switches are essential safety components for trucks as they help prevent theft, tampering, electrical fires, and battery drain. Founded in 1924, Cole Hersee is committed to improving vehicle safety by partnering with ECCO Safety Group Australia (ESGA) to establish and implement safety standards for trucks that drive onto mining sites. Its products are also manufactured in its ISO 9001:2008-certified facility and undergo strict testing to ensure safety and reliability.
