(888) 312-8812 Login SignupBENDIX K046157 AD-9 Air Brake Dryer - with Drain Valve, Service New
Tap to view 1 more
$1,05649
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 3
BENDIX K046157 Part Description
Manufacturer
Product Description
Air Dryer
Features & Benefits
- Designed to collect and remove moisture as well as solid, liquid, and vapor contaminants from the air before entering the air brake system
- Consists of a screw-in type desiccant cartridge and a die-cast aluminum end cover, which contains a safety valve, check valve assembly, and a purge valve housing assembly aristotle
- Has three female pipe threaded air connections
- Operates alternately between the charge cycle and the purge cycle
- Offers ease of serviceability since replaceable assemblies can be serviced without the need to remove the air dryer from the vehicle
- Extends the service life of the air brake system
- Helps prevent air brake system freeze up, avoid costly downtime, and reduce maintenance costs
Courtesy of Bendix – All rights reserved
Bendix AD-9 Air Brake Dryer
The Bendix AD-9 air brake dryer makes sure only clean, dry air gets into the different components of your air brake system. With this product, you don’t have to manually drain the reservoirs on a daily basis just to keep your air brake system working at its best.
BENDIX K046157 Specifications
Product Attributes
| New Or Remanufactured | New |
| Series | AD-9® |
| Air Dryer Type | Stand-Alone |
| Body Mounting | A~ .425 Hole with 3/8-24 UNF-2A Bolted Joint (8x) |
| Cartridge Stabilizer Ring Included | Yes |
| Cartridge Thread | 5/8-11 UNC-2A |
| Cartridge Type | PuraGuard (Coalescing) |
| Cautionary Note(s) | Do not replace PG cartridge with Standard/GC cartridge. |
| Clamp Band Angle (CW from SUP) | Not applicable to this part |
| Clearance to Remove Cartridge | 11.00 IN |
| Control Port | 1/4-18 NPT |
| Cut-In Pressure | Not applicable to this part |
| Cut-Out Pressure | Not applicable to this part |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | Not applicable to this part |
| Extended Purge Port | Not applicable to this part |
| Governor Included | No |
| Governor Mounting Bracket | Not applicable to this part |
| Governor Mounting Bracket Angle (CCW from SUP) | Not applicable to this part |
| Governor Type | Not applicable to this part |
| Heater / Thermostat Rating | 12V / 75W |
| Heater Connector Color | White |
| Heater Connector Type | Metri-Pack 280 Series 2-Way Sealed Connector (Male) |
| Lower Mounting Bracket | .41 IN x 1.15 IN Slot (2x) |
| Lower Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Market Indicator | Aftermarket New |
| Maximum Inlet Temperature | 160 AdegF (71 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Purge Exhaust Port | Standard |
| Purge Valve Type | Hard Seat |
| Purge Volume | Standard |
| Remote Fill Feature | Not applicable to this part |
| Remote Purge Port | Not applicable to this part |
| Safety Valve Opening Pressure | 200 PSI |
| Supply Port | 1/2-14 NPT |
| Turbo Cut-off Function | Not applicable to this part |
| Upper Mounting Bracket | .39 IN x 1.15 IN Slot (2x) |
| Upper Mounting Bracket Angle (CCW from SUP) | Loose in Box |
| Upper Mounting Bracket Height (from Lower Mounting Bracket) | Loose in Box |
| Upper Mounting Type | Strap (Stainless Steel) |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8421398015 |
| UPC | 04068078215852 |
| VMRS Code | 013010252 |
BENDIX K046157 Cross References
BENDIX K046157 Customer Reviews
No reviews yet
Be the first to review this product!
BENDIX K046157 Manufacturer Information
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
