(888) 312-8812 Login SignupDANA SPICER 810656-4614 Drive Shaft
*Representative image - actual part not displayed
$1,03449
Limited availability at this price!
365 Day Lead Time
Get as soon as Thursday, Mar 16
DANA SPICER 810656-4614 Part Description
Manufacturer
Product Description
Drive Shaft
Features & Benefits
- Dana manufactured Spicer Driveshafts are engineered, tested, and manufactured to meet or exceed OE requirements.
- Dana manufactured Spicer driveshafts are designed to be drop-in replacements, eliminating assembly time.
- Meets or exceeds the performance requirements of the original factory driveshaft
Specifications
| Brand | Spicer |
| Series | 1760 |
| Tube Size (MM) | 101.6 x 3.40 |
| Tube Size (IN) | 4.00 x .134 |
| Slip (MM) | 133.4000 |
| Slip (IN) | 5.2520 |
| Length End To End Collapse(MM) | 1573.2125 |
| Length End To End Collapse(IN) | 61.9375 |
| Tube Length (MM) | 1179.5125 |
| Tube Length (IN) | 46.4375 |
| Material | Steel |
| Phased - Degrees | N |
| VMRS | 024000000 |
| Weight | 91.74 LB |
| Country of Origin | United States |
DANA SPICER 810656-4614 Specifications
Product Attributes
| Series | 1760 |
| Material | Steel |
| Tube Length (In) | 46.4375 IN |
| Tube Length (Mm) | 1179.5125 MM |
| Tube Size (in) | 4.0000 x 0.1340 IN |
| Tube Size (mm) | 101.6000 x 3.4000 mm |
| Phased - Degrees | 0.0000 |
| Unwelded/Welded Assembly | Unwelded |
| Shaft Material | Steel |
| Max Slip (IN) | 5.2520 |
| Max Slip (MM) | 133.4000 |
| Notes | Driveshaft |
| CL Yoke To CL Yoke (IN) - COLL | 61.9375 |
| CL Yoke To CL Yoke (MM) - COLL | 1573.2125 |
| Mid Slip (MM) | 66.7000 |
| Mid Slip (IN) | 2.6260 |
| Cv Joints Included | No |
| Slip Assembly | No |
| Phased (Yes/No) | No |
| 1/2 Max Slip (IN) | 2.6260 |
| 1/2 Max Slip (MM) | 66.7000 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913566395 |
| VMRS Code | 024000000 |
DANA SPICER 810656-4614 Cross References
| Brand | Part Number |
|---|---|
| Link-Belt | L8A0208 |
| Navistar | DS8106564614 |
| Volvo | SP 8106564614 |
DANA SPICER 810656-4614 Customer Reviews
No reviews yet
Be the first to review this product!
DANA SPICER 810656-4614 Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
DANA SPICER 810656-4614 Questions & Answers
No questions yet
Be the first to ask a question about this product!
