BENDIX 801931 Part Description
Manufacturer
Product Description
Solenoid Valve
Features & Benefits
- Stand-alone solenoid supports application-defined normally open or closed plumbing
- Incorporates a 2-way circular DIN connector with an 8.5-ohm coil
- IP69K enclosure protection suits exposed pneumatic-control installations around the chassis
- Handles operating pressure up to the 181 psi maximum
Bendix Air Brake Solenoid Valve
Built for exposed chassis locations, the Bendix Air Brake Solenoid Valve pairs pneumatic switching with a protected 12V electrical interface. Its 12V coil connects through a 2-way circular DIN interface, while the enclosure carries IP69K protection for harsh chassis environments. The Bendix 801931 is rated for operating pressure up to 181 psi and can be applied with the intended normally open or normally closed plumbing. Matching circuit behavior, connector type, and pressure capability together gives technicians a more useful installation check than housing shape alone.
BENDIX 801931 Specifications
Product Attributes
| Cautionary Note(s) | Max. Torque < 18 lb-ft. Install fittings no more than 1 turn. |
| Coil Resistor | 8.5 Ohms |
| Connector Type | 2-Way Circular DIN (ISO 15170-1 Twist-Lock) |
| Current (Nominal) | 1.4 A |
| Delivery Port | 1/4-18 NPT (Female) |
| Ingress Protection Rating | IP69K |
| Market Indicator | Aftermarket New |
| Maximum Operating Pressure | 12.5 Bar (181 PSI) |
| Maximum Operating Temperature | 176 AdegF (80 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | A~ 8.5 mm (2x) |
| Operating Pressure Range | 0 - 12.5 Bar (181 PSI) |
| Operation | Solenoid State (NO / NC) is determined by application plumbing |
| Product Type | Stand-Alone |
| Service Port | 1/8-27 NPT (Male) |
| Supply Port | 1/4-18 NPT (Female) |
| Voltage (Nominal) | 12 VDC |
Additional Information
| Country of Origin (Primary) | PL |
| UPC | 07894294761593 |
| VMRS Code | 013011077 |
BENDIX 801931 Cross References
| Brand | Part Number |
|---|---|
| BW801931 |
