(888) 312-8812 Login SignupDANA SPICER 5-450X Universal Joint Greaseable Bradley to 1610 Series BP X WB Style
Tap to view 9 more
$63249
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
DANA SPICER 5-450X Part Description
Manufacturer
Product Description
Universal Joint Greaseable Bradley to 1610 Series BP X WB Style
Features & Benefits
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Bearing cups are heat treated for strength; precision-ground and case-hardened for durability.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
U-joint kit - Series 6875
Special Note: Lead Time135 Days
DANA SPICER 5-450X Specifications
Product Attributes
| Material | Steel |
| Bearing Cap Diameter (1) | 1.875 IN |
| Bearing Plate (1) | 5.312 IN |
| OEM Series | 1610/Bradley |
| Type | BP/WB Style |
| Converts This Series | BRADLEY |
| Pilot Diameter | 5.606 in |
| To This Series | 1610 |
| Distance Between Bolts (2) | 2.400 IN |
| Wb Type (2) | HWD |
| Bearing Cap Type | BP/WB Style |
| Grease Zerk Included | Yes |
| Pre Greased | No |
| Grease Fitting Location | Side of Cross |
| Greaseable | Yes |
| Bearing Cap Diameter A (mm) | 47.625 MM |
| Bearing Cap Type A | Bearing Plate |
| Bearing Cap Type B | HWD |
| Hardware Included | Yes |
| Length A (In) | 5.312 IN |
| Length A (mm) | 134.925 MM |
| Mounting Hardware Included | Yes |
| Wing Bearing Type | HWD |
| Wing Bearing Type Pilot Diam. | 5.606 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708996810 |
| UPC | 00023913126360 |
| VMRS Code | 024002046 |
DANA SPICER 5-450X Cross References
| Brand | Part Number |
|---|---|
| BMY | 12308476 |
| Baer Brake Systems | 12308476 |
| Dana Commercial Vehicle Service Parts | 2104-5450X, DANA5450X |
| FMS Corp | 12308476 |
| International Harvester (IHC) | 5450X, E5450X |
| Mack | 2104-5450X |
| Navistar | 5450X, DS5450X, E5450X |
| Paccar Parts | 5-450X |
| Volvo | 2104-5450X, SP 5450X |
DANA SPICER 5-450X Customer Reviews
No reviews yet
Be the first to review this product!
DANA SPICER 5-450X Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
