(888) 312-8812 Login SignupDANA SPICER 070CS55004G-780M Coupling Shaft
*Representative image - actual part not displayed
$96899
Limited availability at this price!
365 Day Lead Time
Get as soon as Friday, Apr 7
DANA SPICER 070CS55004G-780M Part Description
Manufacturer
Product Description
Coupling Shaft
Features & Benefits
- Dana manufactured Spicer Driveshafts are engineered, tested, and manufactured to meet or exceed OE requirements.
- Dana manufactured Spicer driveshafts are designed to be drop-in replacements, eliminating assembly time.
- Meets or exceeds the performance requirements of the original factory driveshaft
Coupling Shaft - Series 1305
Special Note: Lead Time30 Days
DANA SPICER 070CS55004G-780M Specifications
Product Attributes
| Series | SPL070 |
| Tube Length (In) | 30.7087 IN |
| Tube Length (Mm) | 780.0000 MM |
| Tube Size (in) | 3.5000 x 0.0950 IN |
| Tube Size (mm) | 88.9000 x 2.4100 mm |
| Phased - Degrees | 0.0000 |
| Unwelded/Welded Assembly | Welded |
| Shaft Material | Steel |
| Max Slip (IN) | 4.3307 |
| Max Slip (MM) | 110.0000 |
| Notes | Coupling Shaft |
| CL Yoke To CL Yoke (IN) - COLL | 44.5472 |
| CL Yoke To CL Yoke (MM) - COLL | 1131.5000 |
| Mid Slip (MM) | 55.0000 |
| Mid Slip (IN) | 2.1654 |
| CL Yoke To CL Bearing (MM) | 870.9000 |
| CL Yoke To CL Bearing (IN) | 34.2874 |
| Cv Joints Included | No |
| Slip Assembly | No |
| Phased (Yes/No) | No |
| 1/2 Max Slip (IN) | 2.1654 |
| 1/2 Max Slip (MM) | 55.0000 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708998180 |
| UPC | 00023913514372 |
| VMRS Code | 024002062 |
DANA SPICER 070CS55004G-780M Cross References
| Brand | Part Number |
|---|---|
| Navistar | DS070CS55004G780M |
| Volvo | SP 070CS55004G780M |
DANA SPICER 070CS55004G-780M Customer Reviews
No reviews yet
Be the first to review this product!
DANA SPICER 070CS55004G-780M Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
