(888) 312-8812 Login SignupRAYBESTOS 680313PER Raybestos Specialty - Street Performance S-Groove Brake Rotor
$26149
Limited availability at this price!
In Stock
Get it by Thursday, Sep 3
RAYBESTOS 680313PER Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance S-Groove Brake Rotor
Application Summary
2010-2005 Ford Mustang Front
RAYBESTOS 680313PER Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.8 IN |
| Center Hole Diameter | 71.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 11.535 IN |
| Outside Diameter | 293 MM |
| Overall Height | 1.89 IN |
| Overall Height | 48 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Mounting Bolt Hole Diameter | 0.588 IN |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Stud/Lug Hole Quantity | 5 |
| Solid Or Vented Type Rotor | Vented |
| Mounting Bolt Hole Quantity | 5 |
| Material | Cast Iron |
| Mounting Bolt Hole Diameter | 14.95 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352747940 |
RAYBESTOS 680313PER Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 145616, YH145616 |
| Advance Auto Parts | N1000297722APO, YH145616C, YH145616P |
| AutoZone | 54130, 54130DG |
| BENDIX | 145616, PRT5616 |
| BRAKEBEST | BD126198 |
| BREMBO | 27407 |
| BrakeBest | 680313, 680313FZN, 680313PER, 680313R, 680313RGS |
| Brembo | 09.B589.10 |
| CENTRIC | 120.61085, 121.61085 |
| Casting Numbers | 211690-C, 326216 |
| Centric Parts | 120.61085, 121.61085, 126.61085CSL, 126.61085CSR, 126.61085SL, 126.61085SR, 127.61085L, 127.61085R, 128.61085CL, 128.61085CR, 128.61085L, 128.61085R, 227.61085L, 227.61085R, 320.61085, 320.61085F, 321.61085 |
| Dura Corp | BR54130, BR5413002 |
| DuraGo | BR54130 |
| FORD | 4R3Z1125AA |
| MOTORCRAFT | BRR138 |
| Mighty Distributing System | 54130 |
| Motorcraft | NBRR86 |
| Newtek Automotive USA | 54130 |
| PowerStop | AR8173EVC |
| Qualis | 54130 |
| TopNotch | TN680313GEO |
| UAP | 54130 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51723 |
| WABCO - Archived | PS126198 |
| WAGNER BRAKE | BD126198 |
| WORLDPAC | 1407-26862 |
| Wagner Brake | BD126198E |
| Winhere | 6620512 |
RAYBESTOS 680313PER Fits Vehicles
- Ford Mustang (2005-2010)
RAYBESTOS 680313PER Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 680313PER Questions & Answers
No questions yet
Be the first to ask a question about this product!
