RAYBESTOS 96301 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
Raybestos Specialty - Street Performance Brake Rotor
RAYBESTOS 96301 Specifications
Product Attributes
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.636 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.354 IN |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 4.409 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.43 IN |
| Outside Diameter | 10.31 IN |
| Overall Height | 1.79 IN |
| Center Hole Diameter | 66.95 MM |
| Discard Thickness | 9 MM |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 112 MM |
| Nominal Thickness | 10.9 MM |
| Outside Diameter | 261.85 MM |
| Overall Height | 45.45 MM |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999544940 |
RAYBESTOS 96301 Cross References
| Brand | Part Number |
|---|---|
| ATE BRAKE PRODUCTS | 411137 |
| Advance Auto Parts | 141426, YH141426, YH141426C |
| AutoZone | 3206, 3206DG |
| Autospecialty | EBR217, EBR217E, EBR224 |
| Autoxtra | 61921, AX3206 |
| Beck/Arnley | 083-2084 |
| Bendix | 141426 |
| Bosch | 36010953 |
| Brake Headquarters | BR07240 |
| BrakeBest | 36010953, 96301, 96301R, 96301RGS, BD61921, 96302RGS |
| Brembo | 08.2950.20, 25050, 08.2950.24 |
| CENTRIC | 121.35010 |
| California Drum & Rotor | 61921 |
| Casting Numbers | 210995-C, 32061, 325819 |
| Centric Parts | 120.35010, 121.35010, 125.35010, 126.35010CSL, 126.35010CSR, 126.35010SL, 126.35010SR, 127.35010L, 127.35010R |
| Century | 9413 |
| Continental-ContiTech | CW11137 |
| Dayton Walther | D7339 |
| Delphi | RB308 |
| Dura Corp | BR3206 |
| DuraGo | BR3206 |
| EIS Brakes | D17415 |
| Eurorotor | ME160 |
| GREN | 430401 |
| Girling | GR241, GR242 |
| ITM Engine Components | 1602719 |
| Interbrakes | MR111P |
| Mercedes-Benz | 2014211212 |
| Midas | BR1445 |
| Mighty Distributing System | 3206 |
| Newtek Automotive USA | 3206 |
| PRONTO | BR3206 |
| Promax | 14-3206 |
| Qualis | 3206 |
| Qualitee International | 64-13-050 |
| Quality Brand | 3206 |
| Quinton Hazell | BDC3444 |
| Roadmates | 526610, 526611 |
| Rockhill | 3206 |
| Standard Rotors and Drums | 3206 |
| TRW | 1584, DF1584S |
| TruStar | 413050, R13050 |
| UAP | 3206 |
| Universal | 110060 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X50428 |
| Vera | 3402805 |
| WAGNER | BD61921 |
| Wagner Brake | BD61921 |
| Winhere | 441019, YH1336 |
