RAYBESTOS 782881R Part Description
Manufacturer
Product Description
Disc Brk Rotor
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
Disc Brk Rotor
RAYBESTOS 782881R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.835 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Inside Diameter | 8.268 IN |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Diameter | 0.669 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Outside Diameter | 12.992 IN |
| Overall Height | 2.047 IN |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Construction | Full Cast |
| Grade Type | Regular |
| Misc. Holes | 5 |
| Center Hole Diameter | 72 MM |
| Discard Thickness | 26 MM |
| Inside Diameter | 210 MM |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 17 MM |
| Nominal Thickness | 28 MM |
| Outside Diameter | 330 MM |
| Overall Height | 52 MM |
Additional Information
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213424522 |
RAYBESTOS 782881R Cross References
RAYBESTOS 782881R Fits Vehicles
- Jeep Grand Cherokee (2022-2024)
- Jeep Grand Cherokee L (2022-2024)
RAYBESTOS 782881R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 782881R Manufacturer Information
For ultimate braking power, trust only the best in brakes—Raybestos®. This industry giant has been revolutionizing people’s perception of brakes and braking performance for over 100 years now. Raybestos’ unwavering commitment to providing the automotive aftermarket with top-caliber brake parts makes it the most sought-after brand of brake solutions for commercial vehicles, motorhomes, buses, performance vehicles, and other automotive applications. With its cutting-edge technology and outstanding research and product development capabilities, this brand produces a comprehensive line of brake products that adhere to OE specifications and meet stringent industry standards. From pads to rotors, calipers to cylinders, Raybestos ensures dependable brake parts that deliver the best-in-class performance and unparalleled driving safety that customers expect from an industry leader.
