FRAM CH10246 - Full-Flow Lube Oil Filter
$1049
MSRP: $16.90
Save: $6.41
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
FRAM part description
Product Description
FRAM, CH10246, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 4.134 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.063 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring Inside Diameter | 2.461 IN |
| O-ring Outside Diameter | 2.600 IN |
| O-ring Thickness | 0.138 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.264 in |
| Outer Diameter Top | 2.264 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.365 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Country of Origin (Primary) | AR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100539014 |
| UNSPSC | 15121501 |
Part Interchanges
- Champ P981
- Bosch 72260WS
- Casite Filters CF643
- Hastings LF643
- K&N PS-7027
- Pennzoil PZ171
- Promotive PH5839
- Group 7 V5839
- ACDelco PF101G
- Purolator L15839
- Quaker State QS171
- Wix 57674
- LUBER-FINER P981
- Carquest 84674
- Service Champ CF5839
- Mann-Filter HU612/2X
- Certified CCH10246
- General Motors 55576499
- Hengst E614HD256
- Warner WP981
- Opel 5650359
- Champion 55674T
- Mobil 1 M1C-257
- Pronto PO-5839
- MicroGard MGL10246
- Performax PO-171
- NAPA ProSelect Filters 27674
- MotoMaster MCH10246
- Defense Filters DL10246
- STP S10246
- Parts Master 67674
- Premium Guard PG5839
- MAHLE OX254D4ECO
- NAPA 7674
- Purolator BOSS PBL15839
- PurolatorONE VO-98
- FVP G7674
- Hastings LF643F
- ACDelco PF2257G
- ACDelco PF2264G
- Wix WL10331
- Carquest R84674
- Mann-Filter ML1053
- General Motors 55588497
- General Motors 55594651
- General Motors 55594652
- General Motors 93185674
- Champion COC10246
- Mobil 1 M1C-257A
- MAHLE OX401D
- Carquest Premium Filters 84674
- K&N HP_7027
- Mighty Distributing System M981
- Mahle OX254D4ECO
- Factory Motor Parts G7674
- STP Filters S10246
- NAPA Gold Filters 7674
- Valvoline VO-98
- Champion Filters 55674T
- ECOGARD X5839
- Prime Guard Filters - Archived POF5839
- NAPA Platinum Filters 7674
- Warner Filters WP981
- PureZone 8-57674
- Purolator TECH TL15839
- PurolatorONE PL15839
- FRAM Tough Guard TG10246
- FRAM Ultra Synthetic XG10246
- FRAM Core COR10246ACC
- FRAM Force FF10246
- FRAM Titanium FS10246
- FRAM Drive FD10246
- FRAM Pro FP10246
- FRAM Synthetic Endurance FE10246
- Parts Master 67674X
- Champion Filters COC10246
- FRAM Pro FP10246BP
- MicroGard MGL57674
- MicroGard Select MSL57674
- Mahle OX401D
- STP Filters S10246ML
- STP Filters S10246XL
FRAM CH10246 Cross Reference
We have 10 alternatives for the CH10246 by FRAM:
Fits Vehicles
- Suzuki Aerio (2002)
- GMC Terrain (2018-2019)
- Pontiac G3 (2009-2010)
- Chevrolet Equinox (2018-2019)
- Buick Cascada (2016-2019)
- Chevrolet Colorado (2017-2022)
- Chevrolet Malibu (2016-2019)
- GMC Canyon (2017-2022)
- Chevrolet Cruze Limited (2016)
- Buick Encore (2013-2021)
- Pontiac G3 Wave (2009)
- Chevrolet Trax (2013-2021)
- Chevrolet Sonic (2012-2020)
- Chevrolet Cruze (2011-2015, 2017-2019)
- Chevrolet Aveo (2009-2011)
- Chevrolet Aveo5 (2009-2011)
- Suzuki Swift+ (2009)
- Saturn Astra (2008-2009)
