MONROE 72296 Part Description
Manufacturer
Product Description
OESpectrum Suspension Strut
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Rod displaced valving, tuned specifically to each vehicle, adjusts to road extremes to provide consistency and a smooth ride (on most applications)
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration (on most applications)
- LONGER SERVICE LIFE -- Chrome-plated piston, bronze reinforced rod guide bearing and special single lip seal provide durability and longer service life (where applicable)
- OPTIONAL DUST BOOT/JOUNCE BUMPER -- Protective dust boot reduces dirt and moisture, while jounce bumper reduces severe suspension movement (both sold separately)
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 72296 Specifications
Product Attributes
| Compressed Length | 13.39 IN |
| Extended Length | 20.12 in |
| Travel Length | 6.73 in |
| Body Length | 13.11 IN |
| Body Type | B11 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Strut Charging Type | Gas Charged Unit - Strut Rod Will Extend Automatically |
| Parts Pack(s) | P00808 |
| Mounting Hardware Included | Yes |
| Body Diameter | 1.771 IN |
| Compressed Length | 340.1 MM |
| Extended Length | 511 MM |
| Travel Length | 170.9 MM |
| Gas Charged | Yes |
| Body Length | 333 MM |
| Body Diameter | 45 MM |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | KR |
| Canadian Harmonizing Tariff Code | 8708801910 |
| Harmonized Tariff Code (Schedule B) | 8708801300 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| UPC | 00048598039668 |
| UNSPSC | 25172007 |
MONROE 72296 Cross References
| Brand | Part Number |
|---|---|
| 72296ST, GD9Z5420554AA | |
| AutoZone | ST3313611L |
| Chevrolet | 96408661, 96408662, 96408663, 96408664, 96408735, 96653231, 96653232, 96653233, 96653234, 96980824, 96980825, 96980826, 96980827, 96980828, 96980829 |
| FCS | 331605L |
| FCS Auto Parts | 331605L |
| Gabriel | G56886 |
| General Motors | 96980824, 96980826 |
| KYB | 338012, 333418 |
| KYB AMERICA LLC. | 333418, 338012 |
| NAPA Shocks | 72296 |
| OEM | 96980826, 96980824 |
| Pontiac | 96653231, 96653232, 96653233, 96653234, 96653235, 96980820, 96980821, 96980822, 96980823, 96980824, 96980825, 96980826, 96980827, 96980828, 96980829 |
| Sensen | 42130591 |
| Top Quality | 7872296 |
| Unity Automotive | 211201 |
MONROE 72296 Fits Vehicles
- Pontiac G3 (2007-2010)
- Chevrolet Aveo5 (2007-2011)
- Pontiac Wave (2005-2008)
- Chevrolet Aveo (2004-2018)
