(888) 312-8812 Login SignupMOTORAD TA4100 Thermostat Housing Assembly-192 Degrees
Tap to view 6 more
$59849
Limited availability at this price!
In Stock
Get it by Friday, Jun 26
MOTORAD TA4100 Part Description
Manufacturer
Product Description
Thermostat Housing Assembly-192 Degrees
Features & Benefits
- High grade stainless steel and copper construction
- Meets or exceeds OEM standards
- Consistent and precise response to cooling system needs
- Original equipment design for worry-free direct fit replacement
- 100% tested and calibrated
1st to Market
Thermostat Housing Assembly-192 Degrees
MOTORAD TA4100 Specifications
Product Attributes
| Bleeder Hole | Internal component |
| Flange Thickness | Internal component |
| Gasket/Seal Material | Rubber |
| Inlet Port Inside Diameter | N/A |
| Inlet Port Quantity | 0 |
| Jiggle Pin Included | Internal component |
| Number Of Gaskets | 0 |
| Outlet Port Outside Diameter | 0.39, 0.39, 0.58, 0.58, 1.39, 1.44, 0.87, 0.87 in |
| Pulley Included | No |
| Terminal Quantity | 4 |
| Start to Open Temperature | 192 Deg. F |
| Flange Length | Internal component |
| Flange Width | Internal component |
| Gasket/seal Preinstalled | Yes |
| Inlet Port Outside Diameter | N/A |
| Installation Tool Included | No |
| Meets or Exceeds Original Equipment Manufacture Specifications | Yes |
| Number Of Seals | 2 |
| Sensor Included | Yes |
| Terminal Type | Blade |
| Material | Plástico, Metal, Caucho |
| Color | Negro |
| Inside Diameter | 0.68 IN |
| Mounting Hardware Included | No |
| Grade Type | Standard Replacement |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 5 |
| Bolt Hole Center To Bolt Hole Center | 2.32 IN |
| Gasket Type | O-Ring |
| Outlet Port Quantity | 8 |
| Inlet Quantity | 0 |
| Start to Open Temperature | 192 FA |
| Outlet Port Outside Diameter | 0.88 IN |
| Outlet Port Outside Diameter | 22.35 MM |
| Terminal Quantity | 4 |
| Actuator Type | Mechanical |
| Gasket Or Seal Material | Rubber |
| Gasket or Seal Pre-Installed | Yes |
| Gasket Quantity | 0 |
| Seal Quantity | 2 |
| Includes Sensor | Yes |
| Outlet Hose Connection Type | Barbed |
| Connector Shape | Square |
| Terminal Type | Blade |
| Valve Type | Disk |
| Gasket Or Seal Required | Yes |
| Inside Diameter | 17.272 MM |
| Bolt Hole Center To Bolt Hole Center | 15.49 MM |
| Start to Open Temperature | 88.89 CE |
Additional Information
| Harmonized Tariff Code (Schedule B) | 9032100090 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 9032100090 |
| UPC | 00055644996462 |
MOTORAD TA4100 Cross References
MOTORAD TA4100 Fits Vehicles
- Kia Optima (2013-2016)
- Hyundai Sonata (2013-2014)
