(888) 312-8812 Login SignupRAYBESTOS 66947 Raybestos Specialty - Truck Brake Rotor
$122.55
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 66947 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2004-1999 Ford F-150 Rear, 2002-1999 Ford Expedition Rear, 2004 Ford F-150 Heritage Rear, 2002-1998 Lincoln Navigator Rear, 2002 Lincoln Blackwood Rear, 2003-2001 Ford Lobo Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 66947 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.44 IN |
| Center Hole Diameter | 87.4 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.472 IN |
| Discard Thickness | 12 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Mounting Bolt Hole Circle Diameter | 135 MM |
| Mounting Bolt Hole Diameter | 0.61 IN |
| Mounting Bolt Hole Diameter | 15.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.555 IN |
| Nominal Thickness | 14.1 MM |
| Outside Diameter | 13.15 IN |
| Outside Diameter | 334 MM |
| Overall Height | 2.25 IN |
| Overall Height | 57.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730725079 |
RAYBESTOS 66947 Cross References
| Brand | Part Number |
|---|---|
| 74826515, 747730725079 | |
| ADVANCE AUTO PARTS | 145299, N1000190295APO, YH145299, YH145299C, YH145299P |
| AUTOSPECIALTY | AR8582, AR8582E |
| AUTOZONE | 54090, 54090DG, 54090DL, DL54090 |
| BENDIX | 145299 |
| BOSCH | 20010322 |
| BRAKEBEST | 20010322, 66947, 66947FZN, 66947R, 66947RGS, 81-125752, BD125752 |
| BREMBO | 09.8994.85, 27145, 08.8994.81 |
| CENTRIC | 120.65085, 121.65085, 125.65085, 125.65085CRY, 126.65085CSL, 126.65085CSR, 126.65085SL, 126.65085SR, 127.65085CL, 127.65085CR, 127.65085R, 127.65085L, 128.65085CL, 128.65085CR, 128.65085L, 128.65085R, 227.65085L, 227.65085R, 320.65085, 320.65085F, 321.65085 |
| CONTINENTAL-CONTITECH | CW14704 |
| Casting Numbers | 211094-C, 325525 |
| Centric Parts | 120.65085, 121.65085, 125.65085, 125.65085CRY, 126.65085CSL, 126.65085CSR, 126.65085SL, 126.65085SR, 127.65085CL, 127.65085CR, 127.65085L, 127.65085R, 128.65085CL, 128.65085CR, 128.65085L, 128.65085R, 227.65085L, 227.65085R, 320.65085, 320.65085F, 321.65085 |
| DURA CORP | BR54090, BR5409002 |
| DuraGo | BR54090, BR5409002, BR54090-02 |
| FORD | YL1Z2C026AA, YL3Z2C026AA |
| GUARDIAN | 52-125752 |
| MAGMA PRODUCTS | PSR205184 |
| MIGHTY DISTRIBUTING SYSTEM | 54090 |
| MONROE BRAKES | BD125752 |
| MOTORCRAFT | BRR97 |
| Motorcraft | NBRR95 |
| NEOTEK | 1071005GF |
| NEWTEK AUTOMOTIVE | 54090 |
| Newtek Automotive USA | 54090 |
| PARTS MASTER | P125752 |
| PEP BOYS | 54090G |
| POWERSTOP | AR8582EVC |
| PROMAX | 14-54090 |
| PRONTO | BR54090 |
| Parts Master | 125752 |
| QUALIS | 54090 |
| QUALITY BRAND | 54090, Q4121 |
| STANDARD ROTORS AND DRUMS | 54090 |
| THE UNIVERSAL GROUP | 102631 |
| TRUSTAR | 492355 |
| TopNotch | TN66947GEO |
| UAP | 54090 |
| Ultra Brake | 54213 |
| Universal | 102631 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51361 |
| WABCO | PS125752 |
| WABCO - Archived | PS125752 |
| WAGNER | BD125752E, BD125752 |
| WAGNER BRAKE | BD125752, BD125752E |
| WINHERE | 661345, YH1345 |
| WORLDPAC | 1407-25819, 1427-731974 |
RAYBESTOS 66947 Fits Vehicles
- Ford Lobo (2001-2003)
- Ford F-150 Heritage (2004)
- Lincoln Navigator (1998-2002)
- Lincoln Blackwood (2002)
- Ford F-150 (1999-2004)
- Ford Expedition (1999-2002)
