RAYBESTOS 580366 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2009-2006 Pontiac Solstice Rear, 2010-2007 Saturn Sky Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580366 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.756 IN |
| Center Hole Diameter | 70 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.331 IN |
| Mounting Bolt Hole Circle Diameter | 110 MM |
| Mounting Bolt Hole Diameter | 4.331 IN |
| Mounting Bolt Hole Diameter | 110 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.469 IN |
| Nominal Thickness | 11.9 MM |
| Outside Diameter | 10.942 IN |
| Outside Diameter | 277.95 MM |
| Overall Height | 1.638 IN |
| Overall Height | 41.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352476369 |
RAYBESTOS 580366 Cross References
| Brand | Part Number |
|---|---|
| ACDELCO | 177-0996 |
| ADVANCE AUTO PARTS | YH200506 |
| AUTOXTRA | AX900382 |
| AUTOZONE | 41215 |
| BENDIX | PRT5792 |
| BRAKEBEST | 25010704, 580366, 580366R, 580366RGS |
| BREMBO | 27427 |
| CENTRIC | 120.62094, 121.62094, 126.62094CSL, 126.62094CSR, 126.62094SL, 126.62094SR, 127.62094L, 127.62094R, 128.62094CL, 128.62094CR, 128.62094L, 128.62094R |
| Casting Numbers | 326326 |
| Centric Parts | 120.62094, 121.62094, 126.62094CSL, 126.62094CSR, 126.62094SL, 126.62094SR, 127.62094L, 127.62094R, 128.62094CL, 128.62094CR, 128.62094L, 128.62094R |
| DURA CORP | BR55116, BR900382 |
| DuraGo | 900382, BR900382 |
| Dynamic Friction Company | 604-53006 |
| GM | 15147719 |
| General Motors | 15147719 |
| NEWTEK AUTOMOTIVE | 55116 |
| Newtek Automotive USA | 55116 |
| PROMAX | 14-55116 |
| PRONTO | BR900382 |
| QUALIS | 41215 |
| TRUSTAR | 493555 |
| UAP | 55116 |
| WAGNER | BD126453, BD126453E |
| WAGNER BRAKE | BD126453 |
| WINHERE | 661757 |
| WORLDPAC | 1407-80389 |
| Wagner Brake | BD126453E |
RAYBESTOS 580366 Fits Vehicles
- Saturn Sky (2007-2010)
- Pontiac Solstice (2006-2009)
