(888) 312-8812 Login Signup| Gross Weight | 0.040 KG |
| Market Indicator | Aftermarket New |
| Net Weight | 0.040 KG |
| CAN Baud Rate | 250 Kilobaud |
| Cautionary Note(s) | Fastener Torque & Orientation are Critical |
| Connector Orientation | Straight |
| Connector Type | Bosch 7-Pin Connector (Male) |
| Current (Maximum) | 170 mA |
| Ingress Protection Rating | IP50 |
| Maximum Operating Temperature | 185 AdegF (85 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Operating Voltage Range | 8.2 VDC - 16 VDC |
| Overvoltage | 18 Volts |
| Steering Column Shaft Diameter | A~ 25.98 mm |
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (HTS) | 8543709960 |
| VMRS Code | 015002029 |
