*Representative image - actual part not displayed
Centric 130.62066 - Centric Premium Brake Master Cylinder
$11299
MSRP: $135.98
Save: $22.99
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Product Attributes
| Publication Bore [cntrc] | 40mm - 28.6mm |
| Push Rod: Length / Depth [cntrc] In | dmpl |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M12-1.00 bbl |
| Boss, Nipple Or Port: Front, Left: #b [cntrc] | M16-1.50 |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M11-1.50 bbl |
| Boss, Nipple Or Port: Rear: #b [cntrc] | M16-1.50 |
| Weight [cntrc] Lbs | 3.4 |
| Weight [cntrc] Kgs | 1.55 |
| Master Cylinder Bore Diameter Secondary [cntrc] Mm | 28.600 |
| Master Cylinder Bore Diameter Secondary [cntrc] In | 1.126 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Premium |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 11.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 4 |
| Mounting Bracket Included | No |
| Primary Outlet Thread Pitch | 1.50 MM |
| Bore Type | Stepped |
| Primary Outlet Thread Size | M11-1.50 |
| Primary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 40.000 MM |
| Primary Bore Diameter | 1.575 IN |
| Secondary Bore Diameter | 28.600 MM |
| Secondary Bore Diameter | 1.126 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890008002 |
Part Interchanges
CENTRIC 130.62066 Cross Reference
We have 3 alternatives for the 130.62066 by CENTRIC:
Fits Vehicles
- Oldsmobile Toronado (1986-1990)
- Cadillac Seville (1986-1990)
- Cadillac Commercial Chassis (1991-1992)
- Cadillac Fleetwood (1991-1992)
- Cadillac Eldorado (1986-1990)
- Cadillac DeVille (1990-1993)
- Buick Riviera (1986-1990)
- Buick Reatta (1988-1990)
