Centric 130.20102 - Centric Premium Brake Master Cylinder
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Product Attributes
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Weight [cntrc] Kgs | 1.5 |
| Push Rod: Length / Depth [cntrc] In | 0.591 |
| Publication Bore [cntrc] | 24mm |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M12-1.00 bbl |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 3.3 |
| Boss, Nipple Or Port: Rear, Bottom [cntrc] | M12-1.00 bbl |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 24.000 MM |
| Master Cylinder Bore Diameter | 0.945 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 12.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 3 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 24.000 MM |
| Bore Size | 0.945 IN |
| Secondary Outlet Thread Size | M12-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 24.000 MM |
| Primary Bore Diameter | 0.945 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | IT |
| UPC | 805890000235 |
Part Interchanges
CENTRIC 130.20102 Cross Reference
We have 2 alternatives for the 130.20102 by CENTRIC:
Fits Vehicles
- Jaguar XJ6 (1976-1987)
- Jaguar XJ12 (1976-1979, 1981-1986)
- Jaguar Vanden Plas (1982-1987)
