ICON 217708EP Part Description
Manufacturer
Product Description
14-UP RAM 2500 AIR RIDE REAR 2.5 VS PB CDEV PAIR
Features & Benefits
- ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC)
- ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
- One-piece, hard anodized, impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
- Piggyback reservoir design improves heat dissipation to reduce shock fade during prolonged use
- Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
- One-piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- 7/8” diameter induction hardened, chrome plated shock shaft
- PTFE lined spherical bearings and application specific mounting hardware
- 6061 aircraft grade aluminum CNC machined components
- Fully rebuildable and re-tunable
TECH NOTE: Compatible with 0-2” of rear lift over stock on 14-UP Ram 2500 4WD equipped with OE Automatic-Leveling Rear Air-Suspension system
14-UP RAM 2500 AIR RIDE REAR 2.5 VS
ICON 217708EP Specifications
Product Attributes
| Aap_uda_12 | EA |
| Aap_uda_22 | 1 |
| Aap_uda_4 | 55 |
| Add-on Part | 213500 - 14-UP RAM HD IIC INSTALL KIT |
| Adjustable | Electronically |
| Boot Included | yes |
| Bore Diameter | 2.25 IN |
| California Prop 65 Warning | Yes |
| Cylinder Color | Grey |
| Cylinder Material | Aluminum |
| Damping Type | Oil |
| External Reservoir | Yes |
| Gas Charged | Yes |
| Grade Type | Performance |
| Lower Mount Type | Eyelet |
| Mounting Hardware Included | Yes |
| Service Parts | 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL |
| Shaft Diameter | 0.875 IN |
| Shaft Material | Chrome |
| Shock Absorber Body End Measuring Point | Center of Eylet |
| Shock Absorber Rod End Measuring Point | Shoulder of Stem |
| Title | 14-UP RAM 2500 AIR RIDE REAR 2.5 VS PB CDEV PAIR |
| Tube Outside Diameter | 2.5 IN |
| Upper Mount Type | Stem |
Additional Information
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| NAFTA Preference Criterion Code | C |
| UPC | 00840103414591 |
ICON 217708EP Fits Vehicles
- Ram 2500 (2014-2022)
