TrakMotive HY-8090 - CV Axle Shaft
- Part Number
- HY-8090
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$10499
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 52 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .86 |
| Axle Nut Height (mm) | 22 |
| Axle Nut Hex Size (in) | 1.25 |
| Axle Nut Hex Size (mm) | 32 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.5 |
| Axle Nut Length (mm) | 37 |
| Axle Nut Locking Type | Cotter Pin |
| Axle Nut Thread Size | M22x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 27 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 27 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 38.21 |
| Overall Compressed Length (mm) | 971 |
| Axle Nut Socket Size | 32 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084092908 |
Part Interchanges
- ARC 80-5261
- EMPI 80-9291
- Mevotech CV1113
- USA Industries 7092919
- USA Industries AX-92919
- USA Industries AX8819
- American Remanufactured 40-19854S
- Diversified Shafts Solutions 6411N
- Drive Tech America HY-9854A
- Fenwick CV2193
- CARDONE Reman 60-3358
- CARDONE Reman 66-3358
- IMC 40723016
- Carquest Premium AC NCV37539
- Carquest Premium AC NCV37541
- OEM Part Number 4950026670
- OEM Part Number 4950026671
- OEM Part Number 4950026680
- OEM Part Number 4950026681
- OEM Part Number 4950026681SJ
- ODM HY-8-8544A1
- ODM HY-8-8710A
- TrakMotive HY-8090
- ProTech HY10535
- NCV37539
- 88114
- 199090
Fits Vehicles
- Hyundai Santa Fe (2001-2006)
