CENTRIC 125.20017 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.20017 Specifications
Product Attributes
| Weight [cntrc] Kgs | 10.230 |
| Misc Holes [cntrc] | 5 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 22.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 10.000 MM |
| Discard Thickness | 0.394 IN |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12.000 MM |
| Hat Finish | Painted |
| Overall Height | 34.000 MM |
| Overall Height | 1.339 IN |
| Outside Diameter | 280.000 MM |
| Outside Diameter | 11.024 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 134.500 MM |
| Nominal Drum Diameter | 5.295 IN |
| Bearings Included | No |
| Center Hole Diameter | 63.500 MM |
| Center Hole Diameter | 2.500 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.531 IN |
| Stud/Lug Hole Diameter | 13.500 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890315131 |
CENTRIC 125.20017 Cross References
| Brand | Part Number |
|---|---|
| ATE BRAKE PRODUCTS | SP12154, 412154 |
| N/A | BD126595, 412154, 6433120, 1S7W2A315AD, 34252, YH145541, 25693, 34252G, C2S35271, C2S42668, C2S4575, C2S49730, C2S9231, 4098427, 4098428, 1323102, 1506339, 1676983, 4143445, 4176921, 4179406, 1464915, 7149406, 1376138, 1465619, C2S52088, 4141711, 4110588, 980235P, 145541, 880235, DDF1126, DF4218, 90020013 |
| RAYBESTOS | 980235, 980235R |
| Raybestos Brakes | 980235R, 980235 |
CENTRIC 125.20017 Fits Vehicles
- Ford Mondeo (2001-2007)
- Jaguar X-Type (2002-2008)
