CENTRIC 123.65023 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.65023 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.114 |
| Weight [cntrc] Lbs | 11.250 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 64.516 |
| Hub Hole / Register [cntrc] In | 2.540 |
| Height [cntrc] Mm | 71.882 |
| Height [cntrc] In | 2.830 |
| Friction Surface Width [cntrc] Mm | 55.118 |
| Friction Surface Width [cntrc] In | 2.170 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 230.900 MM |
| Maximum Brake Diameter (Discard) | 9.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 269.494 MM |
| Outside Diameter | 10.610 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 14.478 MM |
| Mounting Hole Diameter | 0.570 IN |
| Nominal Drum Diameter | 228.600 MM |
| Nominal Drum Diameter | 9.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052777 |
CENTRIC 123.65023 Cross References
| Brand | Part Number |
|---|---|
| 2601, 102604, 2604DGS, 2604, 52-60787, 5260787, BD60787 | |
| MAGMA PRODUCTS | PMU20056 |
| N/A | 52-60787, 5260787, BD60787, E127-70-028, E128-70-028, 8952, BD8952, D92 040, 63 92 040, 112604, 8952G, 1086, ZZM026251, YL5Z1V126CA, 100975, E2TZ1126A, E3TZ1126A, E4TZ1126C, 202150, 203521, 140461, PDR0461, 6401141, 6401456, 440-1456, 838, AD8523, AD8523E, D2604, E8361, E12770028, E12870028, 87256, 87261, YH140461, X21679, 23019, BD1319, 2601, 2604, 2604DGS, 2604R, 102604, 8842023, 7842023, 78-42023, 78842023, 68075, 36554064 |
| PRONTO | BD8952 |
| RAYBESTOS | 2604, 2604R |
| WAGNER | BD60787 |
CENTRIC 123.65023 Fits Vehicles
- Mazda B3000 (1994-1997)
- Mazda B4000 (1994-1997)
- Mazda B2300 (1994-1997)
- Ford Ranger (1983-1997)
- Ford Bronco II (1984-1990)
- Ford Aerostar (1986-1989)
