CENTRIC 123.63022 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.63022 Specifications
Product Attributes
| Weight [cntrc] Kgs | 6.818 |
| Weight [cntrc] Lbs | 15.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 77.724 |
| Hub Hole / Register [cntrc] In | 3.060 |
| Height [cntrc] Mm | 83.820 |
| Height [cntrc] In | 3.300 |
| Friction Surface Width [cntrc] Mm | 65.024 |
| Friction Surface Width [cntrc] In | 2.560 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 280.900 MM |
| Maximum Brake Diameter (Discard) | 11.060 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 324.104 MM |
| Outside Diameter | 12.760 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 11.684 MM |
| Mounting Hole Diameter | 0.460 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052579 |
CENTRIC 123.63022 Cross References
| Brand | Part Number |
|---|---|
| 122.63022, F1EZ19G490A | |
| N/A | BD60397, 52-60397, 5260397, E128-68-027, E127-68-027, 8887, 123.63022, 8887G, J5352266, 5352266, 205870, 140386, 6401261, 1016, AD8322, AD8322E, D2345, E8358, E12768027, 87057, X21596, BD1080, 2345, 2345R, 2345DGS, 8832022, 78832022, 36542004, 177315 |
| PRONTO | BD8934 |
| RAYBESTOS | 2345R |
| WAGNER | BD60397 |
CENTRIC 123.63022 Fits Vehicles
- Jeep J10 (1974-1978)
- Jeep Wagoneer (1974-1978)
- Jeep Cherokee (1974-1978)
