CENTRIC 123.61029 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.61029 Specifications
Product Attributes
| Weight [cntrc] Kgs | 4.773 |
| Weight [cntrc] Lbs | 10.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 107.950 |
| Bolt Circle Diameter [cntrc] In | 4.250 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 62.992 |
| Hub Hole / Register [cntrc] In | 2.480 |
| Height [cntrc] Mm | 77.978 |
| Height [cntrc] In | 3.070 |
| Friction Surface Width [cntrc] Mm | 42.164 |
| Friction Surface Width [cntrc] In | 1.660 |
| Product Grade [cntrc] | Standard |
| Stud Thread Size | 12 MM |
| Nominal Drum Diameter | 7.000 IN |
| Nominal Drum Diameter | 177.800 MM |
| Outer Cooling Fins | No |
| Outside Diameter | 8.500 IN |
| Outside Diameter | 215.900 MM |
| Bolt Hole Quantity | 4 |
| Maximum Brake Diameter (Discard) | 7.146 IN |
| Maximum Brake Diameter (Discard) | 181.500 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Country of Origin (Primary) | CN |
| UPC | 00805890052241 |
CENTRIC 123.61029 Cross References
| Brand | Part Number |
|---|---|
| 122.61029, F1EZ17D943E | |
| N/A | 52-60791, 5260791, BD60791, 8950, BD8950, 123.61029, 63 92 520, D92 520, 8950C, 8950CG, E4FZ1113B, 140456, PDR0456, 203501, 6401454, 755, AD8129, AD8129E, D2693, 87284, X30723, BD1497, 101602, 1602, 1602R, 1602DGS, 8834029, 7834029, 78834029, 78-34029, 36554026 |
| RAYBESTOS | 1602, 1602R |
CENTRIC 123.61029 Fits Vehicles
- Mercury Lynx (1984-1987)
- Ford Escort (1983-1990)
- Ford EXP (1986-1988)
