CENTRIC 121.45022 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.45022 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 6.590 |
| Weight [cntrc] Lbs | 14.500 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 20.000 MM |
| Discard Thickness | 0.787 IN |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22.000 MM |
| Overall Height | 65.000 MM |
| Overall Height | 2.559 IN |
| Outside Diameter | 275.700 MM |
| Outside Diameter | 10.854 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 77.000 MM |
| Center Hole Diameter | 3.031 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.492 IN |
| Stud/Lug Hole Diameter | 12.500 MM |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890048466 |
CENTRIC 121.45022 Cross References
| Brand | Part Number |
|---|---|
| 9166RGS, 9166, BD60870 | |
| N/A | BD60870, 0832188, 3194, BR3194, 121.45022, 6474200, 64 74 200, FB0533251, 3194G, 106607, 141737, PRT1737, 112940, 86166, 4886166, 345, JBR381, JBR381E, D17280, 1.2632.2.4, 1263224, MZ481V, X50461, 25362, BR1564, 9166, 9166R, 9166RGS, DDF455, DF2606, 8914022, 78-14022, 7814022, 78914022, 60080013 |
| RAYBESTOS | 9166R |
| WAGNER | BD60870 |
CENTRIC 121.45022 Fits Vehicles
- Mazda RX-7 (1986-1991)
